New ABB CI854BK01 3BSE069449R1 AC 800M Controller PROFIBUS DP-V1 Communication Interface Kit

Product Details

Kit Contents (CI854BK01): CI854B Communication Interface, TP854 Baseplate .

Related Product Model Recommendations

Payment & Delivery

FAQs

Q1: What is the primary function of the CI854BK01?

It is a PROFIBUS DP-V1 communication interface module that connects the AC 800M controller to PROFIBUS field devices. It acts as a PROFIBUS DP Master, managing data exchange with remote I/O, drives, and intelligent instruments. The module communicates with the controller via the CEX-Bus and supports line redundancy (dual PROFIBUS ports) and master redundancy (two CI854B modules) .

Q2: Does the CI854BK01 support redundancy?

Yes. The module supports two levels of redundancy:

• Line Redundancy: The two PROFIBUS ports can be connected to separate cable routes. If one cable fails, communication automatically switches to the backup line.

• Master Redundancy: Two CI854B modules can be configured as a redundant master pair. Combined with CPU redundancy (PM86x) and CEX-Bus redundancy (BC810), this creates a fully redundant communication architecture.

Q3: Can the module be replaced while the system is running?

Yes. The CI854BK01 supports hot-swap capability, allowing module replacement without interrupting controller operation or PROFIBUS communication. The configuration is stored in the controller and is automatically reloaded when a replacement module is inserted. However, verify that the replacement module has compatible firmware before installation.

Q4: What is the difference between CI854BK01 and CI854AK01?

The CI854BK01 is the current (B) version, while the CI854AK01 is the earlier (A) version. The B version offers improved firmware compatibility with newer 800xA system versions (6.0.3.2 and onwards). The A version may be required for older 800xA 5.x systems where the B version is not recognized.

Q5: What are the common causes of PROFIBUS communication failures?

Common causes include:

• Missing termination resistors: Ensure 120Ω active terminators are installed at both physical ends of the PROFIBUS segment.

• Incorrect baud rate or address configuration: Verify settings in Control Builder match the actual device configuration.

• CEX-Bus power supply issues: Check that the backplane is providing 24V DC; LED indicators should show PWR and RUN status.

• Cable shielding/grounding problems: Ensure the PROFIBUS cable shield is properly terminated at the cabinet entry point.

• Firmware mismatch: Verify that the module firmware is compatible with the CPU firmware version.
