New Sealed Siemens 6SL3040-1MA00-0AA0 SINAMICS CONTROL UNIT

Product Details

Related Product Recommendations

Hot Selling Products

Payment & Delivery

FAQs

1. What is the Siemens 6SL3040-1MA00-0AA0?

The 6SL3040-1MA00-0AA0 is a SINAMICS S120 CU320-2 Control Unit, the central processing and motion control module for high-performance multi-axis SINAMICS drive systems. It coordinates and controls up to six axes in applications such as machine tools, packaging, and material handling.

2. How many axes can the CU320-2 control?

The CU320-2 can control up to 6 axes (servo or vector-controlled) in a single unit, depending on the required cycle times and control performance . For more axes, additional CU320-2 control units or other SINAMICS S120 control modules can be cascaded.

3. What communication interfaces does the CU320-2 support?

The CU320-2 features PROFINET communication with 2 integrated Ethernet ports (integrated switch) , enabling connection to higher-level automation systems and other SINAMICS devices via PROFINET. It also includes 2 x DRIVE-CLiQ interfaces for connecting to drive components (power modules, motors, sensors).

4. What is the difference between the CU320-2 and the older CU320?

The CU320-2 is a second-generation version of the control unit, offering significantly higher performance, faster processing, and extended functionality compared to the original CU320. It supports more axes, larger programs, and improved communication capabilities. The 6SL3040-1MA00-0AA0 includes integrated PROFINET support.

5. What accessories are available for the CU320-2?

Available accessories include:

• Memory cards for storing application parameters and firmware

• DRIVE-CLiQ cables for connecting to power modules and motors

• Operator panels (such as the AOP30, 6SL3055-0AA00-4CA5) for local operation and diagnostics

• Mounting adapters for installation in cabinets
