The Bently Nevada 330130-080-12-05 is an 8.0-meter armored extension cable for the 3300 XL 8mm Proximity Transducer System. It connects a 3300 XL proximity probe to a Proximitor® sensor, transmitting high-frequency eddy-current signals for vibration and position monitoring on critical rotating machinery.
Item No :
330130-080-12-05Order(MOQ) :
1 PiecePayment :
EXW/CIFProduct Origin :
USAShipping Port :
WuhanLead Time :
3-5daysWeight :
3kg| Specification | Description |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model | 330130-080-12-05 |
| Product Family | 3300 XL 8mm Proximity Transducer System |
| Product Type | Armored Extension Cable |
| Cable Length | 8.0 meters (26.2 feet) |
| Cable Option (12) | FluidLoc™ cable with connector protector |
| Agency Approval (05) | CSA, ATEX, IECEx hazardous area certifications |
| Cable Type | 75Ω coaxial, double-shielded |
| Capacitance | 69.9 pF/m (typical) |
| DC Resistance (Core) | 1.76 ± 0.26 Ω |
| DC Resistance (Jacket) | 0.53 ± 0.11 Ω |
| Operating Temperature | -40°C to +85°C (extended industrial range) |
| Minimum Bend Radius | 50 mm (armored) |
| Connector Type | ClickLoc™ gold-plated brass, finger-tight |
| Outer Diameter | 5.6 mm |
| Weight | Approx. 0.272 – 0.824 kg (varies by source) |
| Country of Origin | USA |
Part Number Breakdown (330130-080-12-05):
330130 – 3300 XL standard extension cable
-080 – Cable length: 8.0 meters
-12 – FluidLoc™ cable with connector protector
-05 – CSA, ATEX, IECEx hazardous area approvals
| Model | Description | Typical Application |
|---|---|---|
| 330130-080-12-05 (this model) | 8.0m armored FluidLoc cable, connector protector, hazardous area approvals | Standard 8m extension with oil protection and certifications |
| 330130-080-03-05 | 8.0m armored cable with connector protector (no FluidLoc) | Armored applications without oil migration concerns |
| 330130-080-00-05 | 8.0m standard (non-armored) cable with approvals | Non-armored applications requiring certifications |
| 330130-040-12-05 | 4.0m armored FluidLoc cable with connector protector and approvals | Shorter length armored FluidLoc applications |
| 330130-080-12-00 | 8.0m armored FluidLoc cable with protector, no approvals | Non-hazardous area FluidLoc applications |
| 330180-90-00 | 3300 XL Proximitor® Sensor, 9.0m system length | Required sensor for 9m system (1m probe + 8m extension) |
Q1: What is the function of the 330130-080-12-05 in a 3300 XL system?
It connects a 3300 XL 8mm proximity probe to a compatible Proximitor sensor, transmitting the eddy-current displacement signal for vibration and position measurement. The extension cable is part of the calibrated electrical length of the system.
Q2: What do the -12 and -05 suffix options mean?
The -12 indicates a FluidLoc™ cable with connector protector for mechanical protection and sealing against oil/moisture migration. The -05 indicates CSA, ATEX, and IECEx hazardous area certifications.
Q3: Can the cable length be modified in the field?
No. Cutting or splicing the cable alters total loop capacitance, which skews the calibrated eddy-current probe scale factor and introduces measurement errors at the Proximitor sensor.
Q4: How do I ensure proper system compatibility?
The total electrical length of the probe plus the extension cable must equal the rated system length of the Proximitor sensor. For this 8.0m cable, you would typically pair it with a 1.0m probe and a 9.0m Proximitor sensor. All components must be from the 3300 XL system for proper calibration.
Q5: What is the minimum bend radius for this armored cable?
The minimum bend radius is 50 mm to prevent damage to the internal coaxial structure and maintain signal integrity.
