The Bachmann AIO208 (part number 00020628-00) is a universal analog input/output module for the M1 automation system, offering 8 configurable channels in a compact form factor. It enables the measurement or output of all standard analog signals, including voltage, current, and temperature inputs from Pt100/Pt1000 RTDs and thermocouples. With per-channel configurability, 16-bit input resolution, a 100 µs refresh cycle, and a configurable digital filter.

The Bachmann AIO216 (part number 00020627-00) is a high-density, universal analog input/output module for the Bachmann M1 automation system. Featuring 16 configurable channels in a compact form factor, it can measure or output all standard analog signals, including voltage, current, and temperature inputs from Pt100/Pt1000 RTDs and thermocouples.With per-channel configurability, 16-bit input resolution, a 100 µs refresh cycle, and a configurable digital filter, this module is ideal for wind power, marine, and heavy industrial applications requiring flexible analog signal conditioning.

The Bachmann AIO208/SI (part number 00023018-00) is a universal analog input/output module from the M200 controller system, featuring 8 galvanically isolated channels that can be flexibly configured as inputs or outputs. Supporting standard current (0/4–20 mA, ±20 mA) and voltage ranges (±10 V to ±100 mV), as well as Pt100 thermocouple inputs, this module provides a 16-bit input and 14-bit output resolution with an adjustable digital filter from 4 kHz to 0.5 Hz per channel.

The Bachmann AI204/4 (00010693-00) is a high-precision analog input module from the Bachmann M1 controller system. Its core function is to convert up to four differential ±10V voltage signals from field sensors into high-resolution 16-bit digital values for processing by the controller. With an extraordinary accuracy of ±0.005% and integrated temperature calibration, this module is designed for demanding industrial measurement applications.

The Bachmann AI204/2 (00010693-10) is a high-precision analog input module from the Bachmann M1 controller system. Its core function is to convert up to two differential ±10 V voltage signals from field sensors into high-resolution 16-bit digital values for processing by the controller. With extraordinary accuracy of ±0.005% and integrated temperature calibration, this module is designed for demanding industrial measurement applications.

The Bachmann AI204/1 (00010693-20) is a high-precision analog input module from the Bachmann M1 controller system. Its core function is to convert one differential ±10 V voltage signal from a field sensor into a high-resolution 16-bit digital value for processing by the controller. With extraordinary accuracy of ±0.005% and integrated temperature calibration, this single-channel module is designed for demanding industrial measurement applications where measurement precision is critical.

The Bachmann DIO248 (00019116-00) is a high-density, multifunctional digital I/O module designed for the Bachmann M1 controller system. Its core function is to control digital field devices—such as contactors, relays, pneumatic and hydraulic valves—while simultaneously reading signals from digital sensors, detectors, or switches. It also integrates high-speed counter and interrupt functions, making it suitable for complex industrial applications requiring fast response and position detection.
