The ProSoft MVI56-MNETR is a Modbus TCP/IP communication module specifically designed for remote chassis applications in the Rockwell Automation ControlLogix platform. What sets this module apart from standard MVI56 modules is its reduced I/O data image size, which optimizes bandwidth usage on process control networks like ControlNet or EtherNet/IP.
This single-slot, backplane-compatible module provides a powerful connection between ControlLogix processors and Modbus TCP/IP networks, allowing seamless data exchange with a wide range of Modbus-compatible devices including Modicon PACs, instruments, and other Modbus TCP/IP servers and clients.
Item No :
MVI56-MNETROrder(MOQ) :
1Payment :
EXWProduct Origin :
USAShipping Port :
Wuhan, Hubei,ChinaLead Time :
3-5daysWeight :
3.5kgProducts Description
ProSoft MVI56-MNETR Modbus TCP/IP Communication Module (Remote Chassis)
Reduced Data Block Module for Remote ControlLogix Racks
| Model Number | MVI56-MNETR |
| Place of Origin | USA |
| Dimension/Weight | 3.5 kg |
| Condition | new and original |
| Warranty | 1 year |
| Shipping term |
DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery Time | 3-5 days |
| Service |
24 Hours Online Service |
Optimized for Remote Chassis: Uses a reduced I/O image size (42 words Input / 42 words Output) to minimize bandwidth usage on ControlNet and EtherNet/IP networks, making it ideal for remote rack installations
Modbus TCP/IP Client/Server Support: Supports both Client (Master) and Server (Slave) modes, providing flexibility for diverse Modbus TCP/IP applications
RSLogix 5000 Integrated: Module communication integrates within RSLogix 5000/Studio 5000 using sample Add-On Instructions (AOI) or ladder logic — no additional programming software required
Large Data Memory: Supports storage and transfer of up to 5,000 16-bit registers between the module and the ControlLogix processor, with user-definable memory mapping
Built-in Diagnostics: Features a 4-character alphanumeric LED display showing module status, IP address, port settings, and error information in plain English — no cryptic codes to decipher
Ethernet Configuration Port: 10/100 Mbps Ethernet port with auto-crossover detection for module configuration and diagnostics via ProSoft Configuration Builder (PCB)
CIPconnect™ Enabled: Allows remote configuration and diagnostic access across multiple bridged EtherNet/IP and ControlNet networks using Rockwell Automation 1756-ENxT and 1756-CNB modules
Industrial-Grade Construction: Built for demanding industrial environments with wide operating temperature range and robust shock/vibration tolerance
Personality Module Support: Optional industrial-grade Compact Flash card stores network and module configuration, allowing quick field replacement by transferring the CF card
| Category | Specification |
|---|---|
| Manufacturer | ProSoft Technology |
| Model Number | MVI56-MNETR |
| Product Type | Modbus TCP/IP Communication Module with Reduced Data Block |
| Platform | Rockwell Automation ControlLogix (1756 chassis) |
| Slot Requirement | 1 single slot |
| Compatibility | Remote chassis / ControlNet / EtherNet/IP applications |
| Parameter | Detail |
|---|---|
| Protocol | Modbus TCP/IP (Client & Server) |
| Ethernet Interface | 1 x 10/100 Mbps RJ45 with auto-crossover detection |
| Supported Modbus Function Codes | Standard Modbus functions including 1, 2, 3, 4, 5, 6, 8, 15, 16 |
| Data Memory | Up to 5,000 16-bit registers, user-definable mapping |
| Floating Point Support | Configurable, including Enron/Daniel formats |
| Parameter | Detail |
|---|---|
| Input Image Size | 42 words (reduced from 250 words of standard MVI56 modules) |
| Output Image Size | 42 words (reduced from 248 words of standard MVI56 modules) |
| Parameter | Detail |
|---|---|
| Backplane Current (5V DC) | 800 mA |
| Backplane Current (24V DC) | 3 mA |
| Parameter | Detail |
|---|---|
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Shock (Operational) | 30 g |
| Shock (Non-Operational) | 50 g |
| Vibration | 5 g from 10 Hz to 150 Hz |
| Protection Rating | IP20 |
| Certification | Rating |
|---|---|
| ATEX | II 3 G EEx nA IIC T6 |
| cULus | Class I, Division 2, Groups A, B, C, D; Temp Code T6 |
| CE | Compliant |
| RoHS | Compliant |
| CSA | Compliant |
Understanding the difference between these modules is critical for selecting the right solution:
| Feature | MVI56-MNET | MVI56-MNETR |
|---|---|---|
| I/O Image Size (Input) | 250 words | 42 words |
| I/O Image Size (Output) | 248 words | 42 words |
| Best Application | Local chassis installations | Remote chassis / bandwidth-limited networks |
| Remote Rack Suitability | May exceed ControlNet bandwidth | Optimized for remote rack use |
Key Advantage of MNETR: The reduced I/O image size uses significantly less bandwidth on process control networks like ControlNet or EtherNet/IP. This makes the MVI56-MNETR the preferred choice for remote rack installations where network bandwidth is a critical resource.
When using ControlNet to access a remote ControlLogix chassis, I/O bandwidth limitations can become a significant issue. Standard MVI56 modules require 250 words of input and 248 words of output—a data load that may exceed available ControlNet bandwidth, depending on other modules in the chassis.
The MVI56-MNETR addresses this challenge with its reduced data block design:
| Component | Standard MVI56 | MVI56-MNETR |
|---|---|---|
| Input Words | 250 | 42 |
| Output Words | 248 | 42 |
| Bandwidth Usage | High | Reduced by ~83% |
The module uses an RPI (Requested Packet Interval) of 5 ms as a good starting value, configurable from 0.2 to 780.0 ms depending on application requirements.
The MVI56-MNETR is ideal for Modbus TCP/IP integration in remote chassis applications:
| Industry | Application |
|---|---|
| Oil & Gas | Connecting Modbus TCP/IP devices to ControlLogix in remote wellhead and pipeline control cabinets |
| Manufacturing | Remote I/O racks in large plants where ControlNet bandwidth must be conserved |
| Water/Wastewater | Distributed SCADA systems with ControlLogix in remote pumping stations |
| Food Processing | Integration with Modbus-compatible instrumentation in production lines |
| Pulp & Paper | Connecting Modbus TCP/IP drives and instruments in remote control cabinets |
| Automotive | Factory automation systems with distributed ControlLogix racks |
