The Bently Nevada 1900/65A-00-01-01-01-00 is a stand-alone, general-purpose equipment monitor designed for continuous vibration and temperature monitoring. It is a cost-effective solution for protecting non-critical machinery like pumps, fans, and motors, offering a flexible alternative to larger, more complex systems such as the 3500 series.
Item No :
1900/65A-00-01-01-01Order(MOQ) :
1 PiecePayment :
EXW/CIFProduct Origin :
USAShipping Port :
WuhanLead Time :
3-5daysWeight :
5kg| Feature | Description |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Family | 1900 Series General Purpose Equipment Monitor |
| Model | 1900/65A-00-01-01-01-00 |
| Core Function | Continuous vibration, position/speed, and temperature monitoring for protection and shutdown applications . |
| Sensor Inputs | 4 channels for vibration/position/speed; supports accelerometers, velocity sensors, and proximity probes . |
| Temperature Inputs | 4 channels; supports E, J, K, T thermocouples and 2/3-wire RTDs . |
| Outputs | 6 programmable relay outputs; 4 configurable 4-20 mA recorder outputs; 1 dedicated buffered output per channel . |
| Power Option | 00 = 18 to 36 Vdc . |
| Display Option | 01 = Additional display (without cable) . |
| Mounting Option | 01 = DIN rail installation . |
| Approval Option | 01 = Multiple hazardous area approvals . |
| Communication | 00 = None (optional Modbus upgrade available via 1900/01) . |
| ADC Resolution | 24-bit . |
| Event Log | 200-entry event list . |
| Configuration | Via 1900 Configuration software over Ethernet . |
| Dimensions | 19.69 cm x 14.94 cm x 7.44 cm . |
| Category | Model | Description |
|---|---|---|
| With Modbus | 1900/65A-00-01-01-01-01 | Same monitor but with the 01 communication option, enabling Modbus over Ethernet/RS232/485 . |
| With Display & Cable | 1900/65A-00-02-01-01-00 | Includes a display with a 10-foot PVC cable . |
| With AC Power | 1900/65A-01-01-01-01-00 | Features the 01 power option for 110-220 Vac external supply . |
| Monitor Only | 1900/65A-00-00-01-00-00 | Basic monitor (no display, 18-36 Vdc, DIN rail, multiple approvals) . |
| Communications Upgrade | 1900/01 | Retrofit kit to add Modbus communications to a monitor without the gateway . |
| 3500-51 | 140482-01 | 133835-02 |
| 3500/15 | 3500/45 | 3500/61 |
| 127610-01 | 140072-04 | 133843-02 |
| 125840-01 | 3500/45 | 3500/61 |
| 125840-02 | 135137-01 | 136711-02 |
| 129486-01 | 135145-01 | 3500/61 |
| 129478-01 | 126632-01 | 3500/62 |
| 133292-01 | 139554-01 | 133811-03 |
| 133300-01 | 139567-01 | 3500/62 |
| 3500/20 | 139978-01 | 136491-01 |
| 125744-02 | 139991-01 | 136499-01 |
| 125744-01 | 3500/32 | 136294-01 |
| 135031-01 | 125712-01 | 136483-01 |
| 125768-01 | 125720-01 | 137110-01 |
| 3500/22M | 3500/33 | 3500/64M |
| 138607-01 | 149986-01 | 3500/65 |
| 138607-02 | 149992-01 | 3500/70M |
| 146031-01 | 3500/34 | 3500/72M |
| 146031-02 | 125696-01 | 149734-08 |
| 147364-01 | 3500/34 | 3500/72M |
Q1: What is the primary application of the 1900/65A monitor?
It is designed for continuous monitoring and protection of general-purpose or non-critical equipment, such as pumps, fans, motors, and compressors, where a full-scale system like the 3500 series is not cost-effective .
Q2: What does the "-00-01-01-01-00" suffix mean?
The suffix defines the monitor's options: 00 = 18-36 Vdc power; 01 = additional display (no cable); 01 = DIN rail mounting; 01 = multiple hazardous area approvals; 00 = no communication .
Q3: What types of sensors does this monitor support?
Each of the 4 transducer inputs can be configured to support 2- and 3-wire accelerometers, velocity sensors, or proximity sensors . The 4 temperature inputs support E, J, K, T thermocouples and 2/3-wire RTDs .
Q4: How is the monitor configured?
Configuration is done using the 1900 Configuration software on a PC. The configuration file is downloaded to the monitor via its built-in Ethernet connection and is stored permanently in non-volatile memory .
Q5: Can this monitor communicate with a DCS or SCADA system?
Yes, if equipped with the Modbus communication option. This model (00 communication) does not include it, but the monitor can be upgraded with the 1900/01 Communications Upgrade to support Modbus over Ethernet and RS232/485.
