The Bently Nevada 125840-01 is a Proximity Probe Cable Assembly designed for use with Bently Nevada's 3300 Series and 3500 Series vibration monitoring systems. This specialized cable provides the critical electrical connection between the proximity probe and the Proximitor® sensor (driver), ensuring reliable transmission of displacement and vibration signals from rotating machinery.
Item No :
125840-01Order(MOQ) :
1 PiecePayment :
EXW/CIFProduct Origin :
USAShipping Port :
WuhanLead Time :
3-5daysWeight :
3kg| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (GE Measurement & Control) |
| Product Number | 125840-01 |
| Product Type | Proximity Probe Cable Assembly |
| Compatible Systems | Bently Nevada 3300 Series, 3500 Monitoring System |
| Connector Type | BNC connector (one end) |
| Cable Length | 1 meter (nominal) |
| Application | Signal transmission for proximity probes |
| Shielding | Coaxial (preferred for low-noise signal transmission) |
| Lifecycle Status | Active / Available |
| Model | Description | Application / Notes |
|---|---|---|
| 125840-01 | Proximity Probe Cable (this product) | Standard cable assembly for 3300/3500 systems; 1m length |
| 125840-02 | Proximity Probe Cable (longer variant) | Similar cable assembly; 2m length |
| 3300 XL 8mm Proximity Probe | Proximity Probe | Compatible probe; uses this cable assembly |
| 3300 XL Extension Cable | Extension Cable | Extends probe connection to Proximitor (if needed) |
| 3300 XL Proximitor Sensor | Proximitor Sensor | Driver module; interfaces with this cable |
| 133292-01 | I/O Module | 3500 series I/O module; interfaces with the system |
| 125744-02 | 139991-01 | 136499-01 |
| 125744-01 | 3500/32 | 136294-01 |
| 135031-01 | 125712-01 | 136483-01 |
| 125768-01 | 125720-01 | 137110-01 |
| 3500/22M | 3500/33 | 3500/64M |
| 138607-01 | 149986-01 | 3500/65 |
| 138607-02 | 149992-01 | 3500/70M |
| 146031-01 | 3500/34 | 3500/72M |
| 146031-02 | 125696-01 | 149734-08 |
| 147364-01 | 3500/34 | 3500/72M |
| 3500/25 | 125704-01 | 140471-01 |
| 149369-01 | 500/50 | 140482-01 |
| 125800-01 | 133388-02 | 135489-01 |
1. What is the Bently Nevada 125840-01?
The 125840-01 is a proximity probe cable assembly designed for use with Bently Nevada's 3300 and 3500 monitoring systems. It provides the electrical connection between the proximity probe and the Proximitor sensor, transmitting displacement and vibration signals for machinery condition monitoring.
2. What is the cable length of this assembly?
The 125840-01 has a nominal length of 1 meter.
3. What connector type does this cable use?
The cable features a BNC-type connector on one end. This connector is commonly used in monitoring systems for its secure and standardized connection, allowing for reliable signal transmission.
4. Which Bently Nevada systems is this cable compatible with?
The cable is compatible with Bently Nevada 3300 Series and 3500 Monitoring Systems. It is typically used with standard 8mm proximity probes in these systems.
