Allen‑Bradley 1756‑L62S GuardLogix® 5562S Safety Controller

Products Description

Allen Bradley 1756-L62S GuardLogix Processor in stock

Key Features

• Dual‑processor safety architecture – certified for SIL 3 (IEC 61508 / EN 62061) and Category 4 / PL e (EN ISO 13849‑1)

• 4 MB standard user memory – ample space for complex control programs and data storage

• 1 MB dedicated safety memory – isolated memory space for safety logic execution

• 478 KB I/O memory – supports up to 128,000 digital I/O and 4,000 analog I/O

• RS‑232 serial port – programming and communication via 1756‑CP3 or 1747‑CP3 cables

• Conformal coating – protects against humidity, contaminants, and corrosive environments

• 2‑slot width – mounts in any slot of a 1756 ControlLogix chassis; requires 1756‑LSP safety partner in the slot immediately to the right

• Programming software – RSLogix 5000 (version 18 or later) / Studio 5000 Logix Designer®

Technical Specifications

Safety Certifications

The 1756‑L62S GuardLogix controller has been type‑approved and certified for use in safety applications up to :

• SIL 3 per IEC 61508 / EN 62061

• Category 4 / PL e per EN ISO 13849‑1

• Meets requirements of the EU Machinery Directive 2006/42/EC

• c‑UL‑us Listed for US and Canada (File E65584); also Listed for Class I, Division 2 Hazardous Locations (File E194810)

System Integration Notes

• Safety Partner Required: The 1756‑L62S must be used with a 1756‑LSP safety partner module. The primary controller and safety partner must be installed in adjacent slots (primary on the left, partner on the right) with identical firmware versions .

• No Built‑in Ethernet: This processor has no embedded Ethernet port. Use 1756‑ENBT, 1756‑EN2T, or other communication modules for EtherNet/IP connectivity .

• Network Support: Supports DeviceNet, ControlNet, and EtherNet/IP via appropriate communication modules; supports CIP Safety over EtherNet/IP .

• I/O Compatibility: Works with both standard and safety I/O modules (e.g., 1756‑IB8S, 1756‑OB8S) in the same chassis .

• Firmware Updates: Use ControlFLASH software for firmware upgrades.

Applications

The 1756‑L62S is ideal for complex safety applications requiring both standard and safety control, including :

• Automotive manufacturing – safety doors, emergency stops, robot safety interlocking

• High‑speed packaging – safety speed monitoring, safety position control, safe stop

• Material handling – conveyor safety protection, area guarding

• Food & beverage – hygienic safety control, emergency shutdown

• Oil & gas / chemical – rotating machinery protection, SIS safety instrumented systems

• Metallurgy & mining – heavy equipment safety interlocks, hazardous area control

Key benefit: The integrated safety architecture allows safety logic and standard control to coexist on a single processor, eliminating the need for a separate safety PLC and simplifying system design
