Allen‑Bradley 1756‑L71S GuardLogix® 5571S Safety Controller

Products Description

Allen Bradley 1756-L71S GuardLogix Processor Safety Memory in stock

Packing&Delivery

In order to save the freight and reduce your budget, we choose the packaging for environment-friendly. We use foam board with 3 cm thick to fill in all around the box inside to protect parts, then use carton to pack the parts, but if they are too heavy, we will customized the wooden box for them.Shipping term DHL Fedex TNT EMS UPS.

Key Features

• 2 MB standard user memory – for general control logic and application code

• 1 MB dedicated safety memory – isolated memory space for SIL 3 safety logic execution

• 0.98 MB I/O memory – supports up to 128,000 digital I/O and 4,000 analog I/O

• 1 USB programming port – for local programming and configuration

• 100 motion axes supported – suitable for integrated motion applications

• 1 GB Secure Digital card (1784‑SD1) – ships with the controller for non‑volatile memory storage

• No lithium battery required – uses 1756‑ESMCAP Energy Storage Module

• Conformal coating – protects against humidity, contaminants, and corrosive environments (on "K" suffix versions)

• 2‑slot width – primary controller + safety partner; mounts in any slot of a 1756 ControlLogix chassis

• Programming software – Studio 5000 Logix Designer® (version 21 or later) / RSLogix 5000 (version 20 or later)

Technical Specifications

Safety Certifications

The 1756‑L71S GuardLogix controller is TÜV Rheinland certified for use in safety applications up to :

• SIL 3 per IEC 61508 / EN 62061

• Category 4 / PL e per EN ISO 13849‑1

• Certified with various international standards, including China CCC, CE, IECEx Scheme, ATEX, and Australian RCM

Important: This controller must be used with a 1756‑L7SP safety partner module to achieve SIL 3 certification. The primary controller and safety partner must be installed in adjacent slots (primary on the left, partner on the right) .

System Integration Notes

• Programming Software: Use Studio 5000 Logix Designer® version 21 or later, or RSLogix 5000 version 20 or later

• No Built‑in Ethernet: This processor has no embedded Ethernet port. Use 1756‑ENBT, 1756‑EN2T, or other communication modules for EtherNet/IP connectivity

• Network Support: Supports CIP Safety over EtherNet/IP for safety interlocking between GuardLogix processors, as well as DeviceNet and ControlNet for safety I/O connectivity

• I/O Compatibility: Works with both standard and safety I/O modules (e.g., 1756‑IB8S, 1756‑OB8S) in the same chassis

• Redundancy: Full controller redundancy is supported

Applications

The 1756‑L71S is ideal for safety applications requiring both standard and SIL 3 safety control, including:

• Automotive manufacturing – safety doors, emergency stops, robot safety interlocking

• High‑speed packaging – safety speed monitoring, safe stop, position monitoring

• Material handling – conveyor safety protection, area guarding

• Food & beverage – hygienic safety control, emergency shutdown

• Oil & gas / chemical – rotating machinery protection, safety instrumented systems (SIS)
