The ABB DO802-eA (3BSE022364R2) is an 8-channel relay output module from the S800L I/O family, designed for use with the ABB Freelance distributed control system (DCS) . Its core function is to convert control signals from the system into robust, isolated switching actions via 8 independent relay outputs, directly controlling actuators, contactors, valves, and indicators in industrial automation applications.
Item No :
DO802-EA 3BSE022364ROrder(MOQ) :
1Payment :
EXWProduct Origin :
SwedenShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5daysWeight :
0.5kgProducts Description
ABB DO802-EA 3BSE022364R2 Digital Output Module in stock
| Model Number | DO802-EA 3BSE022364R2 |
| Place of Origin | Sweden |
| Dimension/Weight | 0.5kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
HART pass-through:
Media: The system has pass-through functionality and can be connected either as local I/O (S800) or as Remote I/O.
Purpose: Makes HART data available for clients, e.g. Fieldbus Builder
Protocol: HART protocol
SW interface: Process data via 4 – 20 mA signal are I/O copied to application variables. HART data (status and diagnostic data) are available via “pass-through”.
HW Interface: S800 I/O modules AI845, AI895, AO845 and AO845 S900 I/O modules AI930/931 and AO930
OPC interface: Yes, via HART OPC server
Key Parameters and Features
| Item | Specifications / Features |
|---|---|
| Number of Channels | 8 channels |
| Output Type | Relay, normally open (NO), 8x1 channel |
| Signal Compatibility | 24-230 V AC/DC |
| Rated Isolation | 250 V |
| System Platform | ABB S800L, compatible with Freelance DCS |
| Mounting | DIN rail installation |
| Operating Temperature | -25°C to +70°C (typical for S800L series) |
| Dimensions (W x H x D) | 58.5 mm x 102 mm x 86.1 mm |
| Weight | Approx. 0.24 kg |
| Certifications | CE, UL, CSA |
Versatile Relay Outputs: The module's standout feature is its relay-based outputs, which allow direct switching of a wide range of AC/DC loads (24-230V). This provides greater flexibility than transistor outputs, as it can handle both AC and DC devices from a single module . The normally open contacts also provide a safe, "dry contact" isolation between the control system and the load.
Robust and Reliable Design: Each of the 8 channels is individually isolated with a rated isolation of 250 V . This protects the control system from field-side surges and noise, ensuring stable operation in harsh industrial environments. The relay mechanism itself provides a high level of protection against short circuits and overloads, often more resilient than solid-state outputs in such fault conditions.
Simple Integration and Maintenance: As part of the S800L series, the module offers simplified installation. It has no jumpers or switches to set; addressing is automatically configured when it's mounted on the DIN rail . The front panel features LEDs for each channel, providing a quick visual indication of the output state for easy on-site troubleshooting .
The DO802-eA is widely used for robust, high-voltage switching in a variety of industries:
General Actuation: Driving contactors, motor starters, and small relays in manufacturing plants.
Process Control: Operating solenoid valves, indicator lamps, and alarms in chemical, oil & gas, and water treatment facilities.
Power Generation: Switching control circuits for auxiliary equipment and safety interlocks.
Building Automation: Controlling lighting, HVAC contactors, and access control systems.
Q1: What is the primary function of the DO802-eA?
A: It is an 8-channel relay output module that provides isolated switching of AC/DC loads up to 230V, based on commands from an ABB Freelance DCS .
Q2: What is the key difference between the DO802-eA and a transistor output module?
A: The DO802-eA uses relay outputs, which are capable of switching both AC and DC loads and provide high isolation. Transistor outputs are typically limited to DC loads and higher switching speeds but are more susceptible to damage from overcurrent or voltage spikes.
Q3: What is the rated isolation voltage?
A: The module features a rated isolation voltage of 250 V .
Q4: What system is the DO802-eA compatible with?
A: It is part of the S800L I/O family and is specifically designed for use with the ABB Freelance DCS .
Q5: Does the module require any jumpers or switches for configuration?
A: No. The DO802-eA has no physical jumpers or switches. Its address and configuration are automatically set when it is installed on the DIN rail .
Q6: What do the LEDs on the front panel indicate?
A: The front panel LEDs show the status of each output channel, providing a quick way to confirm if the output is on or off . Standard module status LEDs (Fault, Run, Warning) are also present to indicate overall health .
Q7: What are the physical dimensions of the module?
A: The module has dimensions of approximately 58.5 mm x 102 mm x 86.1 mm and weighs about 0.24 kg .
The DO802-eA is part of the ABB S800L I/O family. Below are key related models:
| Product/Model | Type | Brief Description |
|---|---|---|
| DO802-eA | Featured Module | 8-channel relay output module for switching AC/DC loads |
| DI802-eA | Digital Input Module | 8-channel digital input module; often paired with DO802-eA for complete control loops |
| DO801-eA | Digital Output Module | Similar output module with different channel count or voltage rating |
| AI801-eA | Analog Input Module | 8-channel analog input module for reading field sensors |
| S800L PS | Power Supply | Power supply module for the S800L remote I/O station |
The ABB DO880 (3BSE028602R1) is a 16-channel high-integrity digital output module from the S800 I/O system, designed for ABB System 800xA DCS, AC 800M, and Symphony Plus controllers.
The ABB AO820 (3BSE008546R1) is a 4-channel bipolar analog output module from the S800 I/O system, designed for ABB System 800xA DCS and AC 800M controllers.The module features individual galvanic isolation per channel and built-in diagnostics, making it a reliable solution for precision control in demanding industrial environments including chemical, oil & gas, and pharmaceutical applications.
The ABB AO890 (3BSC690072R1) is an 8-channel intrinsically safe analog output module from the S800 I/O system, designed for ABB System 800xA DCS and AC 800M controllers. The module features integrated intrinsic safety (Ex ia) protection components on each channel, allowing direct connection to process equipment in hazardous areas (Zone 0/1/2) without requiring external safety barriers.
The ABB AO845 (3BSE023676R1) is an 8-channel analog output module from the S800 I/O system, designed for ABB System 800xA DCS and AC 800M controllers. It provides 4...20 mA current signals to control field actuators such as valves, positioners, and variable speed drives.
The ABB AO845A (3BSE045584R1) is an 8-channel analog output module from the S800 I/O system, designed for ABB System 800xA DCS and AC 800M controllers. It provides 4...20 mA current signals to control field actuators such as valves, positioners, and variable speed drives, while integrated HART pass-through enables two-way digital communication with smart field instruments.
The ABB AO815 (3BSE052605R1) is an 8-channel analog output module from the S800 I/O system, designed for ABB System 800xA DCS and AC 800M controllers. It provides 4...20 mA current signals to control field actuators such as valves, positioners, and variable speed drives, while integrated HART pass-through enables two-way digital communication with smart field instruments.
The ABB AO801 (3BSE020514R1) is an 8-channel analog output module from the S800L I/O system, designed for ABB System 800xA DCS and AC 800M controllers. It provides precise 0...20 mA or 4...20 mA current signals to control field actuators such as regulating valves, positioners, and variable speed drives in process automation applications.
The ABB AO815-eA (3BSE052605R2) is an 8-channel analog output module from the S800 I/O system, designed for the System 800xA DCS and AC 800M controller platform. Each channel provides 4...20 mA (or configurable 0...20 mA) output with HART pass-through communication, enabling seamless integration with smart field instruments such as positioners, valves, and actuators.
