The ABB AO810V2 (part number 3BSE038415R1) is an 8-channel analog output module designed for the ABB S800 I/O system, serving as the "signal translator" that converts digital commands from the control system into precise analog signals for field devices . This module is the direct 1:1 hardware upgrade replacement for the original AO810 (3BSE008522R1), maintaining full compatibility in slot, base, and configuration . It is widely used in process control applications such as power plants, chemical facilities, water treatment, and HVAC systems to drive actuators, control valves, and variable frequency drives.

  • Item No :

    AO810V2 3BSE038415R1

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    Sweden

  • Lead Time :

    3-5days

  • Weight :

    3kg

  • Product Details

    Key Features



    Feature Description
    Channels 8 isolated unipolar analog output channels
    Signal Types 0–20 mA, 4–20 mA (load ≤ 850 Ω), 0–10 V, ±10 V (software configurable)
    Resolution 12–16 bits (varies by source; typical 12–14 bits)
    Accuracy ±0.1% of full scale (typical)
    Response Time < 1 ms (step change)
    Isolation Galvanic isolation between outputs and module bus; reinforced isolation ≥500 V AC
    Diagnostics Continuous self-diagnostics with open-circuit and short-circuit detection; reports faults to controller
    Hot-Swap Supported when used with compatible redundant termination units
    Compatible TUs TU810, TU812, TU814, TU830, TU833

    Physical & Environmental Specifications



    Parameter Specification
    Dimensions (H×W×D) 119 mm × 45 mm × 102 mm
    Weight Approx. 0.2 kg
    Power Consumption Max. 2.2 W
    Operating Temperature 0°C to +60°C
    Protection Rating IP20 (for control cabinet installation)
    Certifications CE, UL, IEC 61010-1, IEC 61326

    Key Advantages

    • Direct Replacement for AO810: Fully backward compatible with original AO810 in slot, base, and configuration — no engineering changes required .

    • Self-Monitoring & Safety: Continuously monitors internal hardware and power supply; enters safe state upon fault detection .

    • High-Density Installation: Compact 45 mm half-width design optimizes cabinet space .

    • Robust Diagnostics: Detects open circuits, excessive load resistance, and reports faults for rapid troubleshooting .

    Recommended ABB Comparable Products



    Model Model Model Model
    AO845A AO820 AO801 AI810
    AI815 AI830A AI835A AI930N
    PM861 PM865 XXD129A01 GJR5253000R0100

    Product Family Notes :

    • AO845A / AO820: HART-enabled analog output modules (require TU812/TU814 base for HART activation).

    • AO801: Lower-cost 8-channel AO option in the S800 series; cost-effective alternative.

    • AI810 / AI815: 8-channel analog input modules (wide slot 59 mm) — companion modules for complete I/O solutions.

    • AI830A / AI835A: 8-channel RTD/TC input modules (half-width 45 mm) — share the same slot type as AO810V2.

    • AI930N: HART-enabled analog input module; pairs with AO820 for HART system symmetry.

    • PM861 / PM865: AC 800M controller hosts; S800 I/O connects via CI801/CI802.

    • XXD129A01 / GJR5253000R0100: Alternative analog output modules in the S800 series with different channel counts (2 or 16 channels).

    FAQ

    Q1: What is the difference between AO810 and AO810V2?

    A: The AO810V2 is the direct hardware upgrade replacement for the original AO810 (3BSE008522R1). It is fully compatible in slot, base, termination unit, and configuration (Keying AE identical). The V2 version features enhanced diagnostics, improved hardware reliability, and extended component lifespan while maintaining 1:1 interchangeability .

    Q2: Which termination units are compatible with AO810V2?

    A: The AO810V2 supports the following ABB termination units: TU810, TU812, TU814, TU830, and TU833 . For HART functionality, TU812 or TU814 bases are required to activate the HART communication path .

    Q3: Can AO810V2 be replaced while the system is running?

    A: Yes, the AO810V2 supports hot-swap when used with compatible redundant termination units. However, before removing the module, ensure the output channel is set to "manual mode" or "safe state" in the logic to prevent valve position fluctuations .

    Q4: What output signals does the AO810V2 support?

    A: The AO810V2 supports software-configurable outputs for 0–20 mA, 4–20 mA, 0–10 V, and ±10 V. The current output can drive up to 850 Ω load at 20 mA .

    Q5: Does AO810V2 support HART communication?

    A: No. The AO810V2 does not support HART. If HART communication is required, consider the AO820 or AO845A models, which provide HART pass-through functionality (requires TU812/TU814 base) .
