The Siemens 6ES7313-1AD02-0AB0 is a CPU module from the SIMATIC S7-300 series. Its core function is to serve as the central processing unit for a programmable logic controller (PLC), executing user programs, managing I/O data, and handling communication with other automation components in small to medium-scale industrial control applications.
Item No :
6ES7313-1AD02-0AB0Order(MOQ) :
1Payment :
EXWProduct Origin :
GermanyShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.551kgSpecifications
6ES7313-1AD02-0AB0 SIMATIC S7-300
| Origin | Germany |
| Net Weight (kg) | 0.551kg |
| Warranty |
1 year |
Key Parameters
| Item | Specifications / Features |
|---|---|
| Product Type | CPU 313 Compact Module |
| Integrated Power Supply | 24 V DC |
| Working Memory | 12 KB (integrated) |
| Load Memory | Requires pluggable Micro Memory Card (MMC); max. 512 KB (for program and data storage) |
| System Platform | Siemens SIMATIC S7-300 series |
| Communication Interface | 1 x MPI (Multi-Point Interface) |
| Typical Bit Processing Time | 0.2 µs |
| I/O Address Area | Max. 256 bytes inputs / 256 bytes outputs |
| S7 Timers/Counters | 128 timers / 64 counters |
| Dimensions (W x H x D) | 0.055 x 13.00 x 8.5 cm |
| Weight | 0.551 kg |
| Product Lifecycle Status | Discontinued (PM500: End of product lifecycle since 01.10.2011) |
Compact and Integrated Design: The module's standout feature is its compact form factor with an integrated 24V DC power supply . This saves valuable space in the control cabinet by eliminating the need for a separate power supply module, making it well-suited for small-scale automation tasks .
Efficient Processing and Communication: With a bit processing time of 0.2 µs and support for the MPI protocol, the CPU provides a solid balance of performance and connectivity for basic control applications . The MPI interface enables straightforward programming, diagnostics, and networking with other SIMATIC devices .
Reliable, Scalable S7-300 Architecture: Designed for the modular S7-300 family, the CPU 313 offers reliable control in a variety of industrial environments . It can be connected to various I/O modules and expansion modules, facilitating system scalability and customization .
The 6ES7313-1AD02-0AB0 is widely used as the core controller for small to medium-sized industrial automation systems, including :
Machine Building: Control of packaging, textile, and handling machines.
Process Automation: Monitoring and control in chemical, pharmaceutical, and water treatment applications.
Factory Automation: Conveyor systems, sorting equipment, and general production line control.
