The B&R 3AI780.6 is a high-performance analog input module from the SYSTEM 2005 product line, engineered for demanding industrial signal acquisition tasks. This module features 8 differential analog inputs with 16-bit resolution for 0 to 25 mA current signals, making it ideal for connecting a wide range of industrial sensors and transmitters.
What sets the 3AI780.6 apart is its single-channel galvanic isolation design—each input channel is electrically isolated from the others and from the PLC system, providing superior protection against ground loops and electrical faults. Additionally, each channel includes a separate galvanically isolated 24 VDC encoder power supply (max. 30 mA per channel), simplifying sensor wiring and eliminating the need for external power supplies.
Item No :
3AI780.6Order(MOQ) :
1Payment :
EXWProduct Origin :
AustriaShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.5kg
The X20PS9500 is a 24 VDC power supply module for B&R's X20 system, designed to supply Compact or Fieldbus CPUs, the X2X Link network, and internal I/O power. It features an integrated RS232 interface and CAN bus, making it a versatile and robust solution for building reliable X20 control systems.
The X20AI2632 is a high-performance analog input module from B&R's X20 system, featuring 2 channels for ±10 V voltage or 0-20 mA current signals. It offers a 16-bit converter resolution with an exceptionally fast 50 µs conversion time for simultaneous input conversion.
The B&R X20AO2632 is a 2-channel analog output module for the X20 system, supporting both voltage and current signals via different terminal connections. Featuring a 16-bit digital converter resolution and a fast 50 µs conversion time, this module delivers precise analog output control for industrial automation applications.
The B&R X20AO2632 is a 2-channel analog output module for the X20 system, supporting both voltage and current signals via different terminal connections. Featuring a 16-bit digital converter resolution and a fast 50 µs conversion time, this module delivers precise analog output control for industrial automation applications.
The B&R X20AI4622 is a 4-channel analog input module from the X20 system, offering flexible configuration for both voltage (±10 V) and current (0–20 mA / 4–20 mA) signals. Featuring a 13-bit (12-bit plus sign) converter resolution and configurable input filter, this module provides reliable signal acquisition for diverse industrial applications.
The B&R X20AI4622 is a 4-channel analog input module from the X20 system, offering flexible configuration for both voltage (±10 V) and current (0–20 mA / 4–20 mA) signals. Featuring a 13-bit (12-bit plus sign) converter resolution and configurable input filter, this module provides reliable signal acquisition for diverse industrial applications.
The B&R X20AI2222 is a 2-channel analog input module from the X20 system, designed for high-precision voltage measurement. Featuring 2 differential inputs for the ±10 V range with 13-bit (12-bit plus sign) converter resolution, this module offers reliable signal acquisition for industrial applications. With a 300 µs conversion time for all inputs, configurable digital filter (cut-off frequency 1 kHz, 3rd-order low pass), and protection against wiring with supply voltage up to ±30 V, the X20AI2222 provides robust performance for voltage monitoring tasks.
The B&R X20AI1744 is a high-precision analog input module from the X20 system, designed specifically for full-bridge strain gauge applications. Featuring a 24-bit sigma-delta converter with configurable data output rates from 0.1 to 7500 samples per second, this module delivers exceptional measurement accuracy for precision weighing, force monitoring, and torque measurement applications. Supporting both 4-wire and 6-wire load cell connections with built-in compensation that eliminates absolute measurement uncertainty, the X20AI1744 is an ideal solution for demanding industrial measurement tasks.
