The B&R 3AI360.60-1 is a high-performance analog input module from B&R Industrial Automation's 2005 system product line. This module is engineered to deliver precise and reliable signal acquisition across three input channels, supporting both voltage and current signals to accommodate a wide range of industrial sensors and transducers.
Item No :
3AI360.60-1Order(MOQ) :
1Payment :
EXWProduct Origin :
AustriaShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.2kgProducts Description
B&R 3AI360.60-1 Analog Input Module
High-Precision 3-Channel Analog Input Module for B&R 2005 Systems
| Model Number | 3AI360.60-1 |
| Place of Origin | Austria |
| Dimension/Weight | 0.05kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
3 Versatile Input Channels: Supports both voltage (±10V) and current (±20mA / 4-20mA) inputs, providing flexibility for diverse field devices
16-Bit Resolution: Delivers high-precision analog-to-digital conversion with an accuracy of ±0.05% of reading + 1 LSB, ensuring reliable measurement data
Fast Response Time: Processes signals in less than 1 ms, supporting high-speed control applications
High Isolation Voltage: 1500 VAC galvanic isolation provides robust protection against electrical noise and ground loops, enhancing system reliability in industrial environments
Wide Operating Temperature Range: -25°C to +70°C, suitable for demanding industrial conditions
24 VDC Power Supply: Standard industrial voltage for easy integration
| Category | Specification |
|---|---|
| Manufacturer | B&R Industrial Automation |
| Model Number | 3AI360.60-1 |
| Product Type | Analog Input Module |
| System Compatibility | B&R 2005 System |
| Input Channels | 3 Channels |
| Input Range (Voltage) | ±10V |
| Input Range (Current) | ±20mA / 4-20mA |
| Resolution | 16 Bits |
| Accuracy | ±0.05% of reading + 1 LSB |
| Response Time | < 1 ms |
| Isolation Voltage | 1500 VAC |
| Operating Temperature | -25°C to +70°C |
| Power Supply | 24 VDC |
The B&R 3AI360.60-1 is ideal for a wide range of industrial automation and process control applications:
Manufacturing Processes: Monitoring pressure, temperature, flow, and level transmitters
Robotics: Feedback from force, torque, and position sensors
Environmental Monitoring: Data acquisition for HVAC and environmental control systems
Machine Building: Integration into packaging, printing, and material handling equipment
The 3AI360.60-1 is a screw-in module designed for the B&R 2005 modular I/O system. It integrates seamlessly with B&R controllers and CPUs, providing reliable analog signal acquisition for your automation projects.
For installation, shielded cables must be used with analog input modules for EMC reasons, and it is recommended to short-circuit unused inputs.
| Detail | Information |
|---|---|
| Condition | New & Original |
| Stock Status | In Stock |
| Warranty | 12 Months |
| Shipping | Fast dispatch upon order confirmation |
