Bently Nevada 330190-035-00-00 3300 XL ETR Extension Cable

Core Advantages

• Extended Temperature Range: The ETR design with special insulation materials supports continuous operation from -51°C to +177°C (-60°F to +350°F), making it ideal for high-temperature applications near turbine casings, compressor housings, and other thermally demanding industrial equipment.

• Complete System Interchangeability: As part of the 3300 XL system, this extension cable is fully interchangeable with other 3300 XL components. Probes, extension cables, and Proximitor Sensors can be replaced without requiring individual bench calibration, significantly reducing maintenance downtime.

• Precise Electrical Characteristics: The cable maintains precise electrical parameters including 75Ω triaxial impedance and matched DC resistance values, ensuring accurate signal transmission and system linearity.

• Reliable Connector Design: Equipped with gold-plated ClickLoc connectors, the cable provides reliable, corrosion-resistant connections with simple finger-tightening. The specially-engineered locking mechanism prevents connectors from loosening during operation.

• Hazardous Area Capable: The cable meets CE, ATEX, CSA, and IECEx certification requirements, supporting installation in explosive atmospheres and SIL 2/SIL 3 functional safety applications.

• Robust Environmental Protection: With an IP67 rating, the cable is protected against dust and water ingress, ensuring reliable performance in harsh industrial environments.

Technical Specifications

Application Scenarios

The Bently Nevada 330190-035-00-00 is essential in various industrial automation systems requiring precise and reliable signal transmission:

• Gas and Steam Turbines: Signal transmission between proximity probes and monitoring systems in high-temperature turbine environments, where standard cables would degrade or fail.

• Centrifugal Compressors: Vibration and position monitoring for high-speed compressors in oil and gas, petrochemical, and process industries where elevated temperatures are common.

• Power Generation Plants: Machinery protection systems for generators and auxiliary rotating equipment in power plants, ensuring continuous operation and early fault detection.

• Oil and Gas Industry: Used to connect proximity probes on turbines or compressors to monitor equipment vibration for safe operation.

• Chemical Processing: Ensures stable signal transmission in reactors or stirring equipment to prevent unplanned shutdowns.

• Manufacturing: Optimizes production efficiency with vibration monitoring of high-speed rotating equipment such as fans and pumps.

What Is Included

• 1 × Bently Nevada 330190-035-00-00 3300 XL ETR Extension Cable

• Original Factory Packaging (New & Original)

Before You Buy

• Stock Status: In Stock – Ready for immediate dispatch.

• Condition: New and Original. Each unit is 100% tested and verified before shipping.

• System Length Verification: The total electrical length of the proximity probe plus extension cable must equal the Proximitor Sensor's configured system length. The 3.5-meter cable is designed to work with probes of corresponding length to form a matched system. Length mismatch will result in measurement errors or signal attenuation.

• Installation: Installation must be performed by qualified technicians. Maintain the minimum bend radius of 25.4 mm and observe proper connector torque specifications during installation. The cable should be stored in a clean, dry environment and protected from sharp bends and mechanical damage.

• Warranty: Comes with a standard 12-month warranty covering defects in materials and workmanship.

Frequently Asked Questions

Q: What does the model number 330190-035-00-00 represent?
A: The model number breaks down as follows: 330190 = 3300 XL ETR Extension Cable series; 035 = 3.5-meter cable length; 00 = Standard cable (non-armored); 00 = No specific agency approval required.

Q: What is the function of this extension cable?
A: It transmits the probe signal to the Proximitor Sensor while preserving calibration accuracy in a 3300 XL system. It is installed between the proximity probe and the Proximitor Sensor.

Q: What is the difference between ETR and standard extension cables?
A: The ETR (Extended Temperature Range) version supports higher operating temperatures. This cable operates from -51°C to +177°C (-60°F to +350°F).

Q: Can this cable be used with existing 3300 systems?
A: Yes, the 3300 XL 8 mm system components are electrically and physically interchangeable with other 3300 series 5 mm and 8 mm transducer system components, allowing backward compatibility.

Q: What is the recommended gap setting for radial vibration monitoring?
A: The recommended gap setting is -9 Vdc, which corresponds to approximately 1.27 mm (50 mils).

Q: Can the cable be cut or shortened during installation?
A: No. Any modification will alter electrical characteristics and affect measurement accuracy. The cable must be used at its specified length.

Q: What certifications does this cable carry?
A: The cable complies with CE, ATEX, CSA, and IECEx certifications, and meets API 670 standards for mechanical configuration, linear range, and temperature stability.

Q: How fast can you ship this module?
A: As this is a stock item, we typically ship within 24 hours of order confirmation via global express services like DHL or FedEx.

Recommending Models

The Bently Nevada 330190-035-00-00 works seamlessly with the following Bently Nevada 3300 XL components:

• 3300 XL 8 mm Proximity Probe: Standard probe for the 3300 XL 8 mm Proximity Transducer System, available in various lengths to match system requirements.

• 330180-X1-05: 3300 XL Proximitor Sensor with 5-meter system length, converting eddy current signals to calibrated voltage output.

• 330190-035-01-00: Armored version of the same ETR extension cable for applications requiring additional mechanical protection.

• 330130-040-00-00: Standard temperature range extension cable for applications with moderate temperature requirements.

• 3500/42M: Proximitor/Seismic Monitor for integrating the sensor signal into the 3500 Machinery Protection System.

• 3500/15: Power Supply Module for providing the -17.5 Vdc to -26 Vdc required by the Proximitor Sensor.
