The Bently Nevada 330104-00-05-10-01-00 is an 8 mm proximity probe from the 3300 XL series, forming part of a high-performance eddy-current transducer system. Its core function is to provide non-contact, high-precision measurements of shaft vibration and position for critical rotating machinery, such as turbines, compressors, and pumps. It converts mechanical motion into a stable, linear voltage signal proportional to the gap between the probe tip and the target surface.
Item No :
330104-00-05-10-01-0Order(MOQ) :
1Payment :
EXWProduct Origin :
USAShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.25kgProduct Showroom
Bently Nevada 330104-00-05-10-01-00
New and Original
More details
|
Country of origin |
USA |
|
Product condition |
New |
|
Warranty |
one year |
|
Payment Method |
T/T, Western Union |
|
Shipping Method |
DHL/FedEX/UPS/TNE/EMS |
Key Parameters
| Item | Specifications / Features |
|---|---|
| Product Type | 3300 XL 8 mm Proximity Probe |
| Probe Diameter | 8 mm |
| Thread Type | Metric M10 x 1 |
| Unthreaded Length | 0 mm |
| Total Case Length | 50 mm |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature ClickLoc™ coaxial connector with connector protector |
| Cable Type | Standard armored cable |
| Probe Material | AISI 303/304 stainless steel case with PPS plastic tip |
| System Platform | Bently Nevada 3300 XL Proximity Transducer System |
| Measurement Principle | Eddy-current displacement measurement |
| Operating Temperature | -52°C to +177°C (-62°F to +351°F) |
High Precision and Interchangeability: As part of the 3300 XL series, this probe provides advanced performance for eddy-current measurements . A key advantage is that components (probes, extension cables, Proximitor sensors) are fully interchangeable without the need for individual matching or bench calibration, simplifying installation and maintenance .
Robust Design for Harsh Environments: The probe is built for durability in demanding industrial settings. The case is crafted from AISI 303/304 stainless steel for corrosion resistance, and the tip is made from PPS, a material known for its thermal and chemical resilience . The armored cable and ClickLoc connectors ensure a secure and rugged installation .
Compliance with Industry Standards: The entire 3300 XL 8mm system fully complies with the American Petroleum Institute's (API) 670 Standard (4th Edition) for machinery protection systems, guaranteeing its suitability for critical applications in oil and gas and other process industries .
The 330104-00-05-10-01-00 is widely used for continuous condition monitoring and machinery protection in heavy industries, including :
Power Generation: Monitoring shaft vibration and rotor position on steam and gas turbines and generators .
Oil & Gas: Safeguarding compressors, pumps, and gas turbines in processing facilities and offshore platforms .
Chemical and Industrial Plants: Supporting predictive maintenance and machine protection for critical rotating assets
