The ABB RTAC-01 (64610805) is a pulse encoder interface module designed specifically for integration with ABB ACS and ACH series variable frequency drives, including the ACS800 family. Its core function is to convert signals from a digital pulse encoder into a format usable by the drive, providing precise motor speed and position feedback for closed-loop control applications.
Item No :
RTAC-01Order(MOQ) :
1Payment :
EXWProduct Origin :
FinlandShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.2kgProducts Description
ABB RTAC-01 Pulse Encoder Interface Module DCS Module in stock
| Model Number | RTAC-01 |
| Place of Origin | Finland |
| Dimension/Weight | 9.6*11.9*5.4cm / 0.2kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
Main Specifications
| Item | Specifications / Features |
|---|---|
| Product Type | Pulse Encoder Interface Module |
| System Platform | ABB ACS800, ACS600, ACH400, ACH500, ACH600 series drives (verify compatibility) |
| Installation | Option slot on the drive's RMIO board or on an external AIMA-01 adapter |
| Encoder Compatibility | Incremental encoders; differential or single-ended (open collector, push-pull) |
| Encoder Supply Voltage | Selectable 15 V DC or 24 V DC |
| Max Input Frequency | 200 kHz (some sources indicate 300 kHz for certain applications ) |
| Speed Feedback Resolution | 15 bits |
| Speed Feedback Accuracy | 50 ppm |
| Max Encoder Cable Length | 300 m (differential push-pull); 200 m (single-ended push-pull); 100 m (open collector/emitter) |
| Diagnostics | Diagnostic LEDs for status indication |
| Power Consumption | Max 140 mA (5 V) + 55 mA (24 V) |
| Protection Rating | IP20 |
| Weight | Approx. 0.09 kg |
| Dimensions | 62 x 94 x 38 mm |
Accurate Speed and Position Feedback: The module's primary function is to provide the drive with high-resolution encoder feedback . This enables applications requiring precise speed regulation, positioning, and synchronization .
Flexible Encoder Compatibility and Installation: It supports various encoder types and signal levels, including TTL and HTL, as well as differential and single-ended connections . The module can be installed directly into the drive's control board or mounted externally using an adapter .
Robust Industrial Design and Diagnostics: The RTAC-01 features diagnostic LEDs for rapid troubleshooting and is designed for the ambient conditions specified for the host drive . It includes built-in isolation to protect against electrical noise .
The RTAC-01 is used in industrial applications where closed-loop motor control is critical, including:
Machine Control: Precise speed and position control in CNC machines, robotics, and packaging machinery .
Material Handling: Synchronizing motors on conveyors and ensuring accurate product positioning .
Process Control: Providing feedback for winding and unwinding operations in industries like paper, textile, and printing .
Q1: Which ABB drives are compatible with the RTAC-01?
A: The RTAC-01 is designed for ACS800 series drives , and is also compatible with ACS600, ACH400, ACH500, and ACH600 series, though specific model verification is recommended .
Q2: What encoder types and signal formats are supported?
A: It supports incremental encoders with differential or single-ended outputs, including open collector, push-pull, TTL, and HTL signal levels .
Q3: What is the maximum encoder input frequency?
A: The maximum frequency is 200 kHz . Some sources mention 300 kHz for certain applications .
Q4: What encoder supply voltage does the module provide?
A: The module provides a selectable supply voltage of either 15 V DC or 24 V DC to power the encoder . For encoders requiring higher power, an external supply may be needed .
Q5: What is the maximum cable length between the encoder and module?
A: This depends on the encoder output type. The maximum recommended length is 300 meters for differential push-pull, 200 meters for single-ended push-pull, and 100 meters for open collector or emitter outputs .
Q6: Is the RTAC-01 the same as the OTAC-01 or NTAC-02?
A: These are different but related pulse encoder interface modules. The OTAC-01 is marketed as a replacement and upgrade solution compatible with several ABB drive series . The NTAC-02 is another pulse encoder interface module for ABB's ACS and DCS drive platforms . Always verify compatibility for your specific drive model.
Q7: How is the RTAC-01 physically installed?
A: It is typically installed into one of the option slots on the drive's RMIO control board . An optional external I/O Module Adapter (AIMA-01) is available for mounting on a DIN rail .
The RTAC-01 is part of ABB's pulse encoder interface module family. Below are key related products for similar or alternative communication needs:
| Product/Model | Type | Brief Description |
|---|---|---|
| RTAC-01 | Pulse Encoder Interface | The featured module, compatible with ACS800 and other drives; incremental encoder interface . |
| OTAC-01 | Pulse Encoder Interface | Replacement/upgrade solution for ACS series drives . |
| NTAC-02 | Pulse Encoder Interface | Pulse encoder interface module for ACS and DCS drive platforms . |
| DSDP150 | Pulse Encoder Input Unit | Upstream encoder input unit for older Advant-based systems . |
| DP820 | Pulse Counter Module | High-speed pulse counter module for ABB S800 I/O systems . |
| AIMA-01 | I/O Module Adapter | External adapter for DIN rail mounting of the RTAC-01 . |
For ACS800 drives: The RTAC-01 is the standard and recommended module for encoder feedback integration .
For system upgrades: The OTAC-01 may offer a modernized drop-in replacement for existing encoder interfaces in ACS series drives .
For integration with S800 I/O: The DP820 is the appropriate pulse counter module for S800 systems .
The part number ABB UNS 0885a-Z V1 (3BHB006943R0001) has a wide range of conflicting descriptions across different sources. Based on the most consistent manufacturer-aligned evidence, it is identified as a Converter Display Board for the UNITROL UN 5000 converter system.
The ABB UNS 0017a-P V1 (HIEE305106R0001) is a Firing Card (Trigger Board) designed for ABB's UNITROL 6000 X-power static excitation systems and legacy high-power thyristor converter cabinets. The board is engineered for high electromagnetic noise environments typical of power generation and heavy industrial drive applications.
The ABB UNS 1860b-P V1 (3BHB001336R0001) is a Measuring Interface Board (MUB) designed for ABB's UNITROL 5000/6000 static excitation systems. The board performs high-precision isolation, filtering, and A/D conversion, converting raw field signals into digital data for the excitation controller (CPU) via the backplane bus.
The ABB AINP-01C is an Input Bridge Control Board / Inverter Trigger Board engineered specifically for the ABB ACS800 series drives. It serves as the core rectifier control component, responsible for generating precision-timed firing pulses to control thyristors in the drive's input bridge.
The ABB AINT-14C (68685826D) is a Main Circuit Interface Board designed for the ABB ACS800 series drives. It serves as the critical signal bridge between the drive's control unit and external automation systems (PLC/DCS), handling analog/digital I/O and DDCS fiber optic communication.
