The ABB PM904F (3BDH001002R0001) is a high-performance central processing unit (CPU) module for the Freelance AC 900F distributed control system (DCS) . Its core function is to serve as the control system's primary processing engine, executing complex automation logic, managing communication with field I/O and higher-level systems, and enabling scalable control for mid-to-large industrial processes.
Item No :
PM904F 3BDH001002R00Order(MOQ) :
1Payment :
EXWProduct Origin :
GermanyShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
1.5kgProducts Description
ABB PM904F 3BDH001002R0001 Process Module for rack I/O in stock
| Model Number | PM904F 3BDH001002R0001 |
| Place of Origin | Sweden |
| Dimension/Weight | 11.5kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
Key Parameters
| Item | Specifications / Features |
|---|---|
| Product Type | Central Processing Unit (CPU) Module |
| System Platform | ABB Freelance AC 900F DCS |
| Processor | 800 MHz PowerPC (II Pro family) |
| Total Memory | 48 MB (16 MB battery-buffered SRAM, 32 MB DRAM) |
| Ethernet Ports | 4 x 10/100 Mbps (RJ45) for control network, redundancy, and Modbus TCP |
| Communication Slots | 4 slots for communication interface modules (e.g., PROFIBUS, CAN) |
| I/O Capacity | Supports up to 10 local S700 I/O modules; up to 1,500 I/O points |
| Redundancy | Supports hot-standby CPU redundancy for high availability |
| Power Supply | 24 V DC (19.2–32.5 V range) |
| Operating Temperature | -20°C to +70°C |
| Weight | Approx. 1.1 kg |
| Lifecycle Status | Active |
High-Performance Processing for Demanding Applications: The module's standout feature is its 800 MHz PowerPC processor. This delivers the computational power needed for fast logic execution, complex PID loops, and rapid task cycle times—configurable from 5 ms—making it suitable for demanding process control applications in power, oil & gas, and chemical plants .
Enhanced Communication and System Integration: The PM904F provides four Ethernet ports and four expansion slots for fieldbus communication modules (e.g., PROFIBUS, CAN) . It supports a wide range of industrial protocols, including Modbus TCP, IEC 60870-5-104, and PROFIBUS DP, ensuring seamless integration with existing plant equipment and higher-level SCADA/800xA systems .
High Availability with Redundancy and Hot-Swap Support: The PM904F can be configured for 1:1 hot-standby CPU redundancy, enabling bumpless automatic switchover in case of a failure to maintain continuous operation . Its hot-swappable design allows for online module replacement, significantly reducing system downtime .
The PM904F is used as a core control element in mission-critical automation across various industries:
Power Generation: Boiler and turbine control, balance of plant (BOP) systems .
Oil & Gas: Refinery process control, pipeline monitoring, and emergency shutdown (ESD) systems .
Chemical & Pharmaceutical: Batch reactor control and safety-critical logic .
Water & Wastewater: Large-scale pump station and filtration plant control .
Q1: What is the primary function of the PM904F?
A: It serves as the central processing unit for the ABB Freelance AC 900F DCS, executing control logic and managing communication with I/O modules and higher-level systems .
Q2: What is the key difference between the PM904F and the PM902F?
A: The PM904F is the "Plus" version, offering more power, four communication slots, and 48 MB of memory. The PM902F is a standard version with two communication slots .
Q3: What are the key memory specifications?
A: It has 48 MB of total memory, which includes 16 MB of battery-buffered SRAM for data retention during power loss .
Q4: Does the PM904F support redundancy?
A: Yes, it can be configured for 1:1 hot-standby CPU redundancy with bumpless transfer for high-availability applications .
Q5: What communication protocols are supported?
A: It supports Modbus TCP, IEC 60870-5-104, and PROFIBUS DP (via optional communication modules), and includes four onboard Ethernet ports .
Q6: Is the module hot-swappable?
A: Yes, it supports hot-swap replacement to minimize system downtime .
Q7: What software version is required for configuration?
A: A minimum of Freelance 2016 software is required, and Freelance 2019 is fully compatible with the PM904F .
Q8: What are the environmental specifications?
A: It operates in industrial environments at -20°C to +70°C and is compliant with G3 standards for harsh conditions .
The PM904F is part of the Freelance AC 900F controller family. Below are key related models and accessories:
| Product/Model | Type | Brief Description |
|---|---|---|
| PM904F | CPU Module | The featured high-performance "Plus" version with 4 communication slots and 48 MB memory . |
| PM902F | CPU Module | The standard version with 2 communication slots for mid-sized applications . |
| PM901F | CPU Module | A "lite" version with reduced memory and 3 Ethernet ports for basic control needs . |
| TD951F | Display Unit | An optional LCD display for local controller status and diagnostics . |
| CI930F | Communication Module | PROFIBUS DP communication interface module . |
| CI910F | Communication Module | CANopen/DeviceNet communication interface module . |
| AI810 / AO815 | I/O Modules | Analog input and output modules for integration with the PM904F . |
For demanding applications: The PM904F is the recommended choice, providing maximum performance, memory, and communication expansion .
For mid-sized control tasks: The PM902F offers a balanced solution with its standard CPU and memory configuration .
For remote/local monitoring: Consider the optional TD951F display unit for added diagnostic capability .
The part number ABB UNS 0885a-Z V1 (3BHB006943R0001) has a wide range of conflicting descriptions across different sources. Based on the most consistent manufacturer-aligned evidence, it is identified as a Converter Display Board for the UNITROL UN 5000 converter system.
The ABB UNS 0017a-P V1 (HIEE305106R0001) is a Firing Card (Trigger Board) designed for ABB's UNITROL 6000 X-power static excitation systems and legacy high-power thyristor converter cabinets. The board is engineered for high electromagnetic noise environments typical of power generation and heavy industrial drive applications.
The ABB UNS 1860b-P V1 (3BHB001336R0001) is a Measuring Interface Board (MUB) designed for ABB's UNITROL 5000/6000 static excitation systems. The board performs high-precision isolation, filtering, and A/D conversion, converting raw field signals into digital data for the excitation controller (CPU) via the backplane bus.
The ABB AINP-01C is an Input Bridge Control Board / Inverter Trigger Board engineered specifically for the ABB ACS800 series drives. It serves as the core rectifier control component, responsible for generating precision-timed firing pulses to control thyristors in the drive's input bridge.
The ABB AINT-14C (68685826D) is a Main Circuit Interface Board designed for the ABB ACS800 series drives. It serves as the critical signal bridge between the drive's control unit and external automation systems (PLC/DCS), handling analog/digital I/O and DDCS fiber optic communication.
The Siemens C98043-A7010-L2-5 is a Field Excitation Power Board designed for the SIMOREG DC-MASTER 6RA70 series of DC drives. This module serves as the core power supply and control unit for the DC motor's field winding, providing stable and precisely regulated excitation current to maintain a consistent magnetic field in the motor.
