The ABB EI811F 3BDH000020R1 is an Ethernet communication module for the ABB AC800F process control system. It uses a 10BASE2 (thin coax) interface to connect the controller to the DigiNet S system bus, enabling high-speed data exchange with HMIs, SCADA systems, and remote I/O stations.
Item No :
EI811F 3BDH000020R1Order(MOQ) :
1 PiecePayment :
EXWProduct Origin :
SwedenShipping Port :
WuhanLead Time :
3-5daysWeight :
3kg| Feature | Description |
|---|---|
| Manufacturer | ABB |
| Model / Order Code | EI811F / 3BDH000020R1 |
| Product Series | ABB AC800F / Freelance 800F |
| Core Function | Ethernet communication for the DigiNet S system bus . |
| Communication Standard | IEEE 802.3 (10BASE2, "Thin Ethernet") . |
| Interface Type | BNC coaxial connector . |
| Data Transfer Rate | 10 Mbit/s (some sources indicate 10/100 Mbps support) . |
| Data Bus | 32-bit with DMA; CPU load < 4% . |
| System Bus | DigiNet S . |
| Backup Battery | Supports optional battery backup (e.g., SB808F) to retain RAM data . |
| Status Indicators | LED for status (green, orange, red) and battery level . |
| Power Consumption | Max 3.1W . |
| Weight | Approx. 170g (with battery) . |
| Category | Model | Description |
|---|---|---|
| Ethernet (10Base2) | EI801F | Earlier module, also uses a BNC coaxial connector . |
| Ethernet (10Base5/AUI) | EI802F | Legacy module with an AUI interface (15-pin connector) . |
| Ethernet (RJ45) | EI812F | Newer standard Ethernet module with 10/100Base-TX RJ45 ports for AC800F . |
| Ethernet (RJ45) | EI813F | Updated standard Ethernet module recommended for new installations . |
| Processor Module | PM802F / PM803F | Main CPU units for the AC800F system that these modules connect to. |
| Battery Backup | SB808F | Optional backup battery unit compatible with the EI811F . |
Q1: What is the primary purpose of the EI811F module?
It provides an Ethernet interface for the ABB AC800F controller, enabling communication on the DigiNet S system bus with HMIs, SCADA systems, and other network devices .
Q2: What type of physical connection does the EI811F use?
It uses a BNC coaxial connector for a 10BASE2 ("Thin Ethernet") network. It does not support a standard RJ45 Ethernet cable directly .
Q3: How does the EI811F differ from the EI801F?
While both use a BNC connector and support the same 10BASE2 standard, the EI811F is a more modern version and is recommended as an upgrade or replacement for the older EI801F module .
Q4: What do the status LEDs on the module indicate?
The LEDs show operating status: green indicates normal operation, orange suggests the module is starting up or in configuration mode, and red indicates a fault. A flashing orange LED typically means the module is not connected to the system bus .
Q5: Is the EI811F still available from ABB?
This module is a legacy product that has been phased out by ABB in favor of newer RJ45-based modules like the EI812F and EI813F. It is now primarily available through the third-party aftermarket or as used spare parts.
C79451-A3494-D501 is a Siemens spare part, specifically a motherboard (base plate) with firmware for the ULTRAMAT 23 gas analyzer.
6SL3210-1KE21-3UF1 SINAMICS G120C RATED POWER 5,5KW
The Siemens 3UF7101-1AA00-0 is a current measuring module for the SIMOCODE pro motor management system. It features a setting current range of 2.4 to 25 A, a straight-through transformer design with a 7.5 mm passage diameter, and an overall width of 45 mm. It supports a rated operational voltage up to 690 V AC, provides overload protection, and has an IP20 protection rating.
The Siemens 6ES7158-0AD01-0XA0 is a DP/DP Coupler from the SIMATIC DP family, designed to connect two independent PROFIBUS DP networks for data exchange. It functions as a two-sided PROFIBUS slave, allowing two DP masters to communicate with each other without requiring detailed checks of the PROFIBUS address fields on either side . The coupler is ideal for implementing communication between two separate machines or control systems, and it supports redundant current infeed for increased availability. The module is classified under Siemens PLM status PM300: Active Product, with a product phase-out planned effective October 1, 2026 .
The Siemens 6SL3054-0EJ01-1BA0 is a SINAMICS S120 CompactFlash card containing firmware V4.8 with the Performance Expansion option and an included license certificate (Certificate of License stored on the card). It is used in SINAMICS S120 drive systems to enable extended performance functions and is required when the application exceeds the basic axis limits.
The ABB TEU411 is a legacy module from the Hartmann & Braun (H&B) Contrans T series.
Siemens 6ES7953-8LF31-0AA0 is a SIMATIC S7 Micro Memory Card designed for S7-300, C7, and ET 200 systems. It offers 64 KB of NFlash memory and is used for program storage and data backup.
The Siemens 6ES7972-0BA20-0XA0 is a SIMATIC DP bus connector for PROFIBUS networks, featuring a swiveling (angled) cable outlet and supporting transmission rates up to 12 Mbit/s. It does not include a PG/PC connection socket.
