The ABB EI801F (3BDH000015R1) is a 10Base2 Ethernet communication module for the ABB AC800F controller. It provides the controller with an interface to the DigiNet S system bus, enabling high-speed data exchange with HMIs, SCADA systems, and other Ethernet-enabled devices.
Item No :
EI801F 3BDH000015R1Order(MOQ) :
1 PiecePayment :
EXWProduct Origin :
SwedenShipping Port :
WuhanLead Time :
3-5daysWeight :
3kg| Feature | Description |
|---|---|
| Manufacturer | ABB |
| Model / Order Code | EI801F / 3BDH000015R1 |
| Product Type | Ethernet Communication Module |
| Communication Standard | IEEE 802.3 (10Base2, "Thin Ethernet") |
| Interface | BNC coaxial connector (RG58U cable, 50 ohm) |
| Data Transfer Rate | 10 Mbit/s |
| Data Bus | 32-bit with DMA; CPU load < 4% |
| System Bus | DigiNet S |
| Power Supply | 5 VDC ±3% |
| Power Consumption | Max 3.1W |
| Backup Battery | Optional, 3.6V 700mAh lithium; retains RAM and RTC for ≥1.5 years |
| Weight | Max 170g (with battery) |
| Operating Temp. | 0 to 60°C |
| Compatibility | ABB AC800F, PM802F, and PM803F controllers |
| Status | Legacy product (now replaced by newer modules) |
| Category | Model | Description |
|---|---|---|
| Ethernet (BNC) | EI811F | Similar BNC module, recommended as a modern alternative to the EI801F . |
| Ethernet (AUI) | EI802F | Legacy module with an AUI connector (thicknet/transceiver) . |
| Ethernet (RJ45) | EI803F | Standard twisted-pair Ethernet module with an RJ45 connector . |
| Ethernet (RJ45) | EI812F / EI813F | Newer generation Ethernet modules, generally recommended for new installations. |
| Processor Module | PM802F / PM803F | The main CPU units for the AC800F system . |
| Battery Backup | SB808F | Optional backup battery unit compatible with the EI801F. |
| 3BHE046836R0102 | 3BHE013088R001 | 3BHE014135R0011 |
| 3BHE027632R0101 | 3BHE014070R0101 | 3BHE037864R0108 |
| 3BSE082896R1 PM858K02 | 3BHE030579R0003 | 3BHE041626R0101 |
| 3BHE009681R0101 5SHY4045L0001 | 3BHE024747R0101 | 3BHE032025R1101 |
| 3BHE030579R0003 | 3BHE024855R0101 | 3BHE024313R0101 |
| 3BHB003041R0101 | 3BHE032025R1101 | 3BHE008128R0001 |
| 3BHB004661R0101 | 3BHE021887R0101 | 3BSE050091R65 |
| 3BHB018162 | 3BHE024577R0101 | 3BHE009319R0001 |
| 3BHB003041R0101 UFC719AE01 | 3BHB003041R0101 | 3BHE020455R0001 |
| 3BSE042238R2 PP846A | 3BHE022293R0101 | 3BHE025088R6618 |
| 3BSE004006R1 CI626V1 | 3PHE022287R0001 | PHARPS3200000 |
| 3BSE018124R1 CI853K01 | PM582-ETH | PHBRC3000000 |
Q1: What is the primary purpose of the EI801F module?
It provides a 10Base2 Ethernet interface for the ABB AC800F controller, enabling communication on the DigiNet S system bus with operator stations, engineering workstations, and other network devices .
Q2: What type of physical connection does the EI801F use?
It uses a BNC coaxial connector for a 10BASE2 ("Thin Ethernet" or "Cheapernet") network . It does not support a standard RJ45 Ethernet cable directly.
Q3: What is the CPU load of this module during operation?
The EI801F uses Direct Memory Access (DMA) technology, resulting in a very low CPU load of less than 4% .
Q4: What is the backup battery used for?
The optional backup battery (e.g., SB808F) preserves the contents of the main RAM memory and the real-time clock in the event of a system power loss, for up to 1.5 years .
Q5: Is the EI801F still available from ABB?
This module is a legacy product that has been largely phased out by ABB in favor of newer Ethernet modules like the EI803F (RJ45) or EI811F (BNC). It is now primarily available through the third-party aftermarket or as used spare parts.
