The Siemens C98043-A1600-L1 (also known as 6RY1243-0AA00) is a regulation board designed for the SIMOREG family of DC drives . As a central component of the SIMOREG control system, this board manages the closed-loop regulation of armature current, speed, and field current, enabling precise and dynamic control of DC motors in heavy industrial applications.
Item No :
C98043-A1600-L1Order(MOQ) :
1Payment :
EXWProduct Origin :
GermanyShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.5kgSpecifications
Siemens C98043-A1600-L1 SIMOREG Control Board
Regulation Board for SIMOREG DC Drive Systems
SIMOREG System Compatibility: Designed specifically for SIMOREG DC converter systems, serving as the central regulation board for motor control
Precise Motor Control: Manages the regulation of armature current, speed, and field current, enabling accurate control of DC motor torque and speed
German Engineering & Manufacturing: Manufactured by Siemens AG in Germany, adhering to stringent quality and industrial standards
Robust Industrial Construction: Built for reliability in demanding industrial environments with wide operating temperature tolerance
Power Supply Compatibility: Designed for use in systems with 380V–500V AC input, 50/60 Hz, with a DC link voltage of 400–560V DC
| Category | Specification |
|---|---|
| Manufacturer | Siemens AG |
| Model Number | C98043-A1600-L1 |
| Alternative Reference | 6RY1243-0AA00 |
| Product Type | SIMOREG Regulation Board / Control Board |
| Product Family | SIMOREG DC Drive Series |
| Function | Armature current, speed, and field current regulation |
| Input Voltage | 380–500V AC, 50/60 Hz |
| DC Link Voltage | 400–560V DC |
| Rated Current | 1,600A |
| Weight | ~0.467 kg / ~0.82 kg (with packaging) |
| Dimensions | Approx. 26 x 23 x 3.5 cm |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Humidity | ≤95% non-condensing |
| Country of Origin | Germany |
| Commodity Code | 85049090 / 85049099 |
| Product Status | Discontinued (End of Life since 30 June 2014) |
The board performs three primary regulation functions:
| Function | Description |
|---|---|
| Armature Current Regulation | Controls the armature current (torque) for precise load management |
| Speed Control Loop | Regulates motor speed based on feedback from tachometer or encoder |
| Field Current Regulation | Manages field current for flux control, including field-weakening above base speed |
The C98043-A1600-L1 has several variants with different suffix codes. Please verify the correct variant for your application:
| Variant | Description | Source |
|---|---|---|
| C98043-A1600-L1 | Standard regulation board | |
| C98043-A1600-L1-03 | Variant with specific firmware/configuration | |
| C98043-A1600-L1-17 | Inverter power board variant; 380-500V AC, 1,600A rated current | |
| C98043-A1600-L1-18 | Converter board for SIMOREG drive systems |
Please verify the specific suffix code required for your drive system before ordering.
The C98043-A1600-L1 is deployed across industries requiring robust DC motor control:
| Industry | Application |
|---|---|
| Steel & Metals | Rolling mill drives, coilers, and uncoilers |
| Mining | Mine hoists, conveyor systems, and crusher drives |
| Marine | Ship propulsion and thruster DC drives |
| Cement | Rotary kiln and mill drives |
| General Industry | Heavy-duty DC motor control in demanding environments |
