Pepperl + Fuchs S1SD-1AI-2C S1SD-1AI-2U Signal Conditioner New in Stock

Pepperl + Fuchs S1SD-1AI-2C S1SD-1AI-2U Signal Conditioner New in Stock

The S1SD-1AI-2C is a 1-channel transmitter power supply and signal splitter from Pepperl+Fuchs. It supplies power to a 2-wire transmitter, processes the 0/4 to 20 mA input signal, and provides two identical isolated 0/4 to 20 mA outputs. This compact device ensures reliable signal transmission and galvanic isolation between field and control circuits.

  • Item No :

    S1SD-1AI-2C S1SD-1AI

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    Germany

  • Shipping Port :

    Wuhan

  • Lead Time :

    3-5days

  • Weight :

    1KG

  • Product Details



    Feature Specification
    Product Type Transmitter Power Supply / Signal Splitter
    Channels 1 input, 2 outputs
    Input Signal 0/4 ... 20 mA (2-wire transmitter)
    Output Signal Dual 0/4 ... 20 mA (load ≤ 300 Ω)
    Supply Voltage 16.8 ... 31.2 V DC
    Accuracy 0.1 % of full-scale value
    Galvanic Isolation Reinforced insulation, 300 V rated / 3 kV test voltage
    Ambient Temperature -25 ... 70 °C (-13 ... 158 °F)
    Mounting 35 mm DIN mounting rail
    Dimensions (W x H x D) 6.2 x 97 x 107 mm (0.24 x 3.82 x 4.21 in)
    Protection Rating IP20
    ATEX / IECEx II 3G Ex nA IIC T4 Gc

    Recommended Accessories

    To complete your system, the following accessories are recommended:

    • Power Feed Module: S1SD-2PF

    • Power Bus (various lengths): POWERBUS-SETL5., POWERBUS-SETH5.

    • DIN Rail Cover: POWERBUS-COV.250

    • End Cap: POWERBUS-CAP



    Payment & Delivery

    FAQs

    Q1: What is the main function of the S1SD-1AI-2C?
    A1: It powers a 2-wire transmitter, receives its 4-20 mA signal, and splits it into two identical, isolated 4-20 mA outputs for sending to two separate control devices.

    Q2: What types of output signals does it provide?
    A2: It provides two outputs, each configurable for either a 0 to 20 mA or 4 to 20 mA signal.

    Q3: What is the accuracy of the signal conversion?
    A3: The module offers a high accuracy of 0.1% of the full-scale value.

    Q4: How is the S1SD-1AI-2C powered?
    A4: It can be powered via its screw terminals or through the optional Power Bus system for easier wiring.
