ABB AC800PEC PPD113 B03-26-100110 (3BHE023584R2634) High-Performance Controller

Core Advantages

• Ultra-Fast Processing Architecture: Features a high-speed CPU combined with FPGA co-processing, delivering deterministic task execution with control cycles below 1ms. The dynamic update rate can reach up to 250μs, meeting the rapid protection requirements of extreme conditions such as turbine load rejection.

• Advanced Communication Capabilities: Equipped with IONet (100 MB Ethernet) for communication with I/O modules, supporting non-redundant, dual-redundant, and triple-redundant configurations. The module uses Ethernet Global Data (EGD) and IEEE 1588 Precision Time Protocol to ensure highly accurate time alignment of data packets between the controller and I/O modules.

• Distributed Intelligent Design: I/O modules contain built-in local processors that support peer-to-peer data communication. In emergency situations (such as rapid acceleration caused by large turbine load rejection), I/O modules can directly compare turbine mechanical power with generator load and quickly command valve closure without going through the main controller‘s lengthy processing cycle.

• High Reliability in Harsh Environments: The metal housing and circuit layout are optimized for strong electromagnetic interference environments. The wide operating temperature range makes it suitable for power plants, water treatment, and industrial facilities without requiring expensive climate control in many locations.

• Flexible Modular Design: As part of the AC 800PEC series, this module features a highly modular design that facilitates functional expansion and system upgrades according to production requirements. It supports multiple mainstream industrial communication protocols for easy integration with other brands of industrial automation equipment.

Technical Parameters

Application Scenarios

The PPD113 B03-26-100110 is essential in various industrial automation and power generation systems requiring precise and reliable control:

• Power System Excitation Control: Core control for synchronous generator static excitation systems (UNITROL), regulating generator output voltage and reactive power with high precision.

• Renewable Energy Control: Fast regulation for large-scale wind power grid-connected converters and photovoltaic inverters, ensuring stable integration with power grids.

• Industrial Drives: High-speed logic operations for medium-voltage high-power frequency converters (such as ACS6000), supporting demanding drive-oriented control and regulation tasks in rolling mills.

• Turbine Monitoring and Protection: Monitoring turbine vibration and displacement, supporting fast protection responses during critical conditions such as load rejection.

• Special Power Supplies: Applications in rail transit traction converters and HVDC transmission monitoring systems.

• Metals Processing: Use as master encoder and drive control for rolling mill automation modernization projects, replacing legacy MP200 controllers.

What Is Included

• 1 × ABB PPD113 B03-26-100110 Controller Module (3BHE023584R2634)

• Original Factory Packaging (New & Original)

Before You Buy

• Stock Status: In Stock – Ready for immediate dispatch.

• Condition: New and Original. Each unit is 100% tested and verified before shipping.

• Installation: Installation must be performed by qualified technicians. Ensure all power sources are disconnected before replacing the module. Please verify that the version suffix matches the original component and confirm the backplane slot specifications in the control cabinet.

• Warranty: Comes with a standard 12-month warranty covering defects in materials and workmanship.

Frequently Asked Questions

Q: What does “PEC” in the model number 3BHE023584R2634 represent?
A: “PEC” stands for Power Electronic Controller, indicating that this module is specifically designed to handle faster electrical switching logic than standard process industrial controllers.

Q: Does this module support online replacement?
A: Due to its involvement in core control logic, it is recommended to replace the module after system shutdown and power-off, and to reload the matching application firmware.

Q: How can I ensure compatibility with my existing system?
A: Please confirm that the specific version suffix of the PPD113B03 matches the original component and verify the backplane slot specifications in the control cabinet.

Q: Does this model handle real-time control requirements?
A: Yes, the AC 800PEC is specifically designed for sub-millisecond, real-time control tasks required in power electronics, with dynamic update rates reaching 250μs.

Q: What software is required for configuration?
A: The module requires ABB‘s proprietary engineering software, such as Control Builder, to configure specific logic and control algorithms. It also supports MATLAB/Simulink for simulation and control application development.

Q: How fast can you ship this module?
A: As this is a stock item, we typically ship within 24 hours of order confirmation via global express services like DHL or FedEx.

Recommending Models

The PPD113 B03-26-100110 works seamlessly with the following ABB AC 800PEC components:

• PPD113B03-26-100100 (3BHE023584R2625): Similar PPD113 variant with 64-bit floating-point processing and fiber optic I/O expansion support.

• PPD113B01-25-111000 (3BHE023784R2530): AC 800PEC controller with integrated I/O (16 DI, 8 DO, 8 AI, 4 AO), PowerPC 7418 processor at 750MHz.

• PCD237A101 (3BHE028915R0101): ABB AC800PEC excitation controller series with dual-channel redundant switching capability.

• UNITROL 1020 (3BHE030579R0007): Excitation system module for precise regulation of generator excitation current.

• PM864AK01 (3BSE018161R1): AC800PEC series CPU module supporting Ethernet/IP, Modbus TCP, and other protocols.
