The ABB PP D113 (3BHE023784R2630) is a high-performance, expandable controller module from the AC 800PEC automation platform. Its core function is to serve as the central processing unit for demanding power electronics applications, managing critical communication and logic execution for systems such as high-voltage inverters, excitation control, and advanced drive systems.
Item No :
AC800PEC PP D113Order(MOQ) :
1Payment :
EXWProduct Origin :
SwedenShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.2kgProducts Description
New and Original ABB AC800PEC PP D113 3BHE023784R2630 DCS Module in stock
| Model Number | AC800PEC PP D113 3BHE023784R2630 |
| Place of Origin | Sweden |
| Dimension/Weight | 9.6*11.9*5.4cm / 0.2kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
Key Parameters and Features
| Item | Specifications / Features |
|---|---|
| Product Type | Expandable Controller Module / Central Processing Unit |
| System Platform | ABB AC 800PEC (Process & Energy Controller) |
| Processor | 750 MHz RISC processor with 64-bit IEEE floating-point unit (FPU) |
| Memory | 64 MB ECC RAM + 16 MB Flash |
| Slot Configuration | U4: CEX2-Bus RS422; U5: Anybus/Modbus RTU; U7-U9: UF D128; U10-U12: Open for expansion |
| Communication Interfaces | Ethernet, PROFIBUS, Modbus TCP/IP, RS-422, Modbus RTU, Anybus |
| Operating Temperature | -25°C to +70°C (some sources indicate -40°C to +85°C) |
| Dimensions (W×H×D) | 145 mm × 450 mm × 100 mm |
| Weight | Approx. 2.59 kg |
| Protection Rating | IP20 |
| Product Status | Discontinued - Available as spare part/stock only |
Modular, Expandable Architecture: The module's standout feature is its multi-slot design, functioning as a "functional base" that allows engineers to mix and match communication and I/O sub-modules. Slots U4 and U5 support specific ANYIO modules, while U7-U9 accept UF D128 modules. Open slots (U10-U12) provide a direct path for future system upgrades without replacing the core controller.
High-Speed Deterministic Control: Designed specifically for power electronics, the PP D113 executes logic with microsecond precision. Its 750 MHz RISC processor and 64-bit FPU enable closed-loop control cycle times as low as 25 microseconds, stabilizing high-frequency drive systems and ensuring synchronized operation in rapid-response power conversion applications.
Customizable Protocol Stack: The multi-slot configuration allows engineers to bridge disparate field networks into a unified AC 800PEC control stream. By populating slots with specific ANYIO modules, the PP D113 can integrate Modbus RTU, Anybus (Profibus, Profinet, DeviceNet), and CEX2-Bus RS422 into a single controller.
Robust Industrial Design: The module features an aluminum housing and operates reliably in harsh industrial environments with a wide temperature range. Its IP20 rating indicates it must be installed within a protective enclosure.
The PP D113 is used as the core control component in demanding power and process applications, including:
Excitation Systems: Central processor for UNITROL 6000 static excitation systems, managing generator voltage regulation and reactive power control
High-Voltage Inverters: Core logic controller for high-power drive systems
Power Generation: Combustion logic, fuel/air ratio control, and drum level regulation in power plants
Industrial Automation: Complex process control in chemical, oil & gas, and water treatment facilities
Q1: What is the primary function of the PP D113 3BHE023784R2630?
A: It is a high-performance, expandable controller module for the AC 800PEC platform, serving as the central processing unit for power electronics applications such as excitation systems and high-voltage inverters. It manages critical communication and logic execution with microsecond-level precision.
Q2: Is the PP D113 still in production?
A: No. The module has been discontinued by ABB. It is available as a spare part through surplus or third-party suppliers. The limited market availability indicates it is primarily used for maintaining existing installations rather than new projects.
Q3: What is the slot configuration of this specific model?
A: This model (B01-26-111000) includes: Slot U4 (ANYIO-1, CEX2-Bus RS422), Slot U5 (ANYIO-2, Anybus/Modbus RTU), Slots U7-U9 (UF D128 modules), and Slots U10-U12 (open for future expansion).
Q4: What communication protocols does the PP D113 support?
A: It supports Ethernet, PROFIBUS, Modbus TCP/IP, RS-422 (CEX2-Bus), Modbus RTU, and Anybus (including Profibus, Profinet, and DeviceNet depending on the selected Anybus insert).
Q5: Can I hot-swap expansion modules in slots U7-U9?
A: No. To protect the sensitive synchronization logic and prevent data corruption, you must power down the AC 800PEC rack before inserting or removing any modules from the PP D113 base unit.
Q6: What are the key considerations when replacing this module?
A: Ensure you have a complete backup of the control program and parameters. Verify firmware compatibility with your system version. The module requires ABB's engineering software (such as Control Builder) for configuration and programming.
The PP D113 is part of the ABB AC 800PEC controller family. Below are key related models and components:
| Product/Model | Type | Brief Description |
|---|---|---|
| PP D113 (3BHE023784R2630) | Featured Module | Expandable controller with CEX2-Bus RS422, Anybus/Modbus RTU, and UF D128 slots |
| PP D113 (3BHE023584R2334) | Variant | Similar controller module with different slot configuration (RS422, Profibus) |
| PP D103 B101 (3BHE020455R0101) | Related Model | Associated AC 800PEC controller module |
| UF D128 | Expansion Module | Analog/digital I/O or communication expansion module for slots U7-U9 |
| ANYIO-1 | Expansion Module | CEX2-Bus RS422 interface module for slot U4 |
| ANYIO-2 | Expansion Module | Anybus/Modbus RTU interface module for slot U5 |
For UNITROL 6000 excitation systems: The PP D113 (3BHE023784R2630) is the correct choice, serving as the central processor for generator voltage regulation.
For high-voltage inverter control: This module provides the deterministic response times required for power electronics applications.
For system expansion: The open slots (U10-U12) allow for future upgrades with additional UF D128 or ANYIO modules without replacing the core controller.
The part number ABB UNS 0885a-Z V1 (3BHB006943R0001) has a wide range of conflicting descriptions across different sources. Based on the most consistent manufacturer-aligned evidence, it is identified as a Converter Display Board for the UNITROL UN 5000 converter system.
The ABB UNS 0017a-P V1 (HIEE305106R0001) is a Firing Card (Trigger Board) designed for ABB's UNITROL 6000 X-power static excitation systems and legacy high-power thyristor converter cabinets. The board is engineered for high electromagnetic noise environments typical of power generation and heavy industrial drive applications.
The ABB UNS 1860b-P V1 (3BHB001336R0001) is a Measuring Interface Board (MUB) designed for ABB's UNITROL 5000/6000 static excitation systems. The board performs high-precision isolation, filtering, and A/D conversion, converting raw field signals into digital data for the excitation controller (CPU) via the backplane bus.
The ABB AINP-01C is an Input Bridge Control Board / Inverter Trigger Board engineered specifically for the ABB ACS800 series drives. It serves as the core rectifier control component, responsible for generating precision-timed firing pulses to control thyristors in the drive's input bridge.
The ABB AINT-14C (68685826D) is a Main Circuit Interface Board designed for the ABB ACS800 series drives. It serves as the critical signal bridge between the drive's control unit and external automation systems (PLC/DCS), handling analog/digital I/O and DDCS fiber optic communication.
The Siemens C98043-A7010-L2-5 is a Field Excitation Power Board designed for the SIMOREG DC-MASTER 6RA70 series of DC drives. This module serves as the core power supply and control unit for the DC motor's field winding, providing stable and precisely regulated excitation current to maintain a consistent magnetic field in the motor.
LF505-S/SP27 Spare Part New in stock 1 year warranty Origin from Romania
C98043-A7002-L4 Spare Part New in stock 1 year warranty Origin from Germany
