Honeywell CC-TSV211 Servo Valve Positioner Module

The Honeywell CC-TSV211 is a high-precision servo valve positioner module from the Series C I/O family, designed for the Experion PKS distributed control system. Its core function is to provide closed-loop positioning control for electro-hydraulic servo valves, typically used in critical turbomachinery applications such as steam and gas turbines. It executes an onboard PID control loop, accepts position feedback from LVDT or RVDT sensors, and outputs a precise current to drive the servo valve coil, ensuring accurate and stable valve positioning.

  • Item No :

    CC-TSV211

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    USA

  • Shipping Port :

    Wuhan, Hubei, China

  • Lead Time :

    3-5 days

  • Weight :

    0.7kg

  • PRODUCT INFORMATION

    Honeywell CC-TSV211 Servo Valve Positioner Module

    Brand Name: Honeywell

    Product Name: CC-TSV211

    Condition: 100%New And Original

    Lead Time: 3-5Days

    Warranty: 1Year



    Key Parameters



    Item Specifications / Features
    Product Type Servo Valve Positioner Module
    Output Channels 2 channels
    Output Types Bipolar current (10–320 mA) or Unipolar current (up to 300 mA)
    Feedback Inputs 2 channels; supports LVDT/RVDT (3-6 wire) or 4-20 mA signals
    Resolution 16-bit DAC for output; 16-bit A/D for feedback
    Onboard Control 2 PID blocks; total loop latency ≤10 ms
    System Platform Honeywell Experion PKS / Series C I/O with C300 Controller
    Galvanic Isolation ±500 VDC
    Power Supply 24 VDC nominal
    Operating Temperature -20°C to +60°C (typical)

    Core Features & Advantages

    • High-Precision Onboard PID Control: The module's standout feature is its integrated PID positioning loop. This allows it to execute closed-loop control with exceptionally low latency (under 10 ms), ensuring fast and stable valve positioning. It can handle a wide range of current outputs (up to 320 mA) to drive various servo valve coils.

    • Robust and Diagnostic-Rich Design: The module features comprehensive diagnostics, including open-wire detection for servo, LVDT, and analog inputs; LVDT core fallout detection; and power supply/memory diagnostics. It also includes a digital dither function (0-10% of FS, 25-60 Hz) to compensate for valve stiction, improving control performance.

    • Flexible I/O and Built-in Safety: It supports two channels of LVDT/RVDT or 4-20 mA feedback, two digital inputs, and two servo/analog outputs. The module supports redundant configurations and can drive the valve to a pre-defined safe state upon detecting an abnormal condition, enhancing system availability and safety in critical applications.

    Typical Applications

    The CC-TSV211 is widely used for critical, high-value equipment control in process and power industries:

    • Turbomachinery Control: Speed governing and fuel control for steam and gas turbines, inlet guide vane (IGV) control for compressors, and anti-surge control.

    • Power Generation: Steam turbine valve actuation and boiler feedwater regulation in thermal and nuclear power plants.

    • Oil, Gas & Chemical Processing: Pipeline pressure regulation and high-precision hydraulic valve control in refineries and chemical plants

    Recommended Products & Accessories

    The following products are essential for deploying the CC-TSV211 in a complete servo valve control system:



    Product/Model Type Brief Description
    CC-PSV201 IOM (I/O Module) Servo Valve Positioner Module. This is the companion IOM module that plugs into the CC-TSV211 IOTA base
    CC-TSV211 IOTA Base The IOTA base provides the redundant 18-inch chassis, terminal blocks, and field wiring interfaces for the CC-PSV201 IOM. Supports two servo valves
    CC-PSV211 Related Module Alternate servo valve positioner module variant for similar applications
    C300 Controller Controller Requires a C300-20msCEE controller to provide the remote setpoint for the PID loop
    C300-20msCEE Controller Variant Specific C300 controller model used with the SVPM module for communication
    Field Wiring Cables Accessory Bulk-terminated cables can be used to simplify field wiring from the IOTA to the patch panel
    24 VDC Power Supply Accessory Required for module operation; the IOTA base includes a built-in 24 VDC bus for power distribution

    Module Relationship Clarification

    Based on the search results, it is important to understand the distinction between the CC-TSV211 and CC-PSV201:



    • CC-TSV211: The IOTA (Input/Output Terminal Assembly) base or "faceplate" that provides the physical mounting, redundant architecture, and field wiring connections for the servo valve positioner module .

    • CC-PSV201: The IOM (I/O Module) —the actual processing module that contains the PID control logic and servo drive electronics. It plugs into the CC-TSV211 base
