The X67AI1223 is a rugged, field-mounted analog input module from the B&R X67 system, specifically engineered for decentralized automation without the need for a control cabinet. Featuring 4 high-precision analog inputs with a ±10 V bipolar voltage range, this module is designed for direct installation on machinery in harsh industrial environments.
In sectors such as mobile automation, heavy-duty outdoor equipment, and large-scale manufacturing lines, the X67AI1223 provides critical sensor feedback with minimal wiring overhead. Its IP67-rated protection ensures reliable data acquisition in the presence of dust, moisture, and high mechanical vibration, enabling a truly distributed control architecture that brings I/O processing closer to the physical process.
Item No :
X67AI1223Order(MOQ) :
1Payment :
EXWProduct Origin :
AustriaShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.5kgProducts Description
B&R X67AI1223 plc module in stock
| Model Number | X67AI1223 |
| Place of Origin | Austria |
| Dimension/Weight | 0.5kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
| Feature | Benefit |
|---|---|
| 4 Analog Inputs, ±10 V | Interfaces with bipolar sensors measuring positive and negative values (e.g., pressure transducers, bidirectional position sensors) |
| 12-bit Resolution | Provides reliable, high-resolution signal conversion for precise control |
| IP67 Protection Rating | Cabinet-free installation directly on machinery; withstands dust, moisture, and vibration |
| Integrated Diagnostics | Per-channel LED status indicators for immediate visual fault detection |
| Open/Short Circuit Detection | Built-in diagnostics for input signal integrity monitoring |
| Configurable Digital Input Filters | Customizable filtering for improved signal stability in noisy environments |
| M12 Connectors | Standardized, watertight connections with optimal shield grounding on all channels |
| Wide Operating Temperature | -25°C to +60°C, suitable for demanding industrial environments |
| Parameter | Specification |
|---|---|
| Model | X67AI1223 |
| Brand | B&R (Bernecker + Rainer) |
| System | X67 System – Field-mounted I/O |
| Number of Inputs | 4 analog inputs |
| Input Range | ±10 V (bipolar) |
| Converter Resolution | 12-bit |
| Status Indicators | Per-channel LEDs, supply voltage, bus function |
| Protection Rating | IP67 (per EN 60529) |
| Electrical Isolation | Channel isolated from bus; channel-to-channel not isolated |
| Input Connections | 4x M12, A-coded |
| X2X Link Connection | M12, B-coded |
| I/O Power Supply | M8, 4-pin |
| Power Consumption (Internal I/O) | 3 W |
| X2X Link Power Consumption | 0.75 W |
| Weight | Approx. 200 g (0.2 kg) |
| Dimensions (W × H × D) | 53 mm × 85 mm × 42 mm |
| Parameter | Specification |
|---|---|
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Transport Temperature | -40°C to +85°C |
| Protection Class | IP67 |
| ATEX | Zone 2, II 3G Ex nA IIA T5 Gc |
| UL/cULus | E115267 – Industrial control equipment |
| HazLoc | Class I, Division 2, Groups ABCD, T5 |
| cCSAus | 244665 – Process control equipment for hazardous locations |
| CE | Yes |
| UKCA | Yes |
Distributed Automation – Cabinet-free I/O directly on machinery
Mobile Equipment – Ruggedized for outdoor and heavy-duty applications
Process Monitoring – ±10 V bipolar signals for pressure, position, and other sensors
Harsh Environments – Dust, moisture, and high vibration areas with IP67 protection
Large-scale Manufacturing – Decentralized control architecture with reduced wiring
Official datasheets are available for download from B&R Automation's documentation portal. For technical support or application inquiries, please contact our team.
Fast Shipping – Worldwide Delivery Available
Items are carefully packaged to ensure safe delivery. Contact us for tracking information and estimated delivery times.
