Beckhoff EL7342 EtherCAT Terminal

Key Parameters and Features

Core Features & Advantages

• Integrated Compact Drive Technology: The module's standout feature is its integration of a complete motion control solution for two DC motors in a single, compact EtherCAT terminal . It combines the motor output stage, an incremental encoder input for each channel, and fast communication via Distributed Clocks, creating a simple yet powerful servo axis .

• Powerful Output with Performance Boost Option: The module provides a strong 3.5 A continuous output current per channel and can be further enhanced with the ZB8610 fan cartridge to deliver up to 6.5 A per channel, offering flexibility to drive more demanding motors without changing the terminal .

• Robust and Reliable Design: Designed for industrial environments, the EL7342 features an output stage that is protected against overload and short circuits . It also provides 500 V electrical isolation from the E-bus and includes LED indicators for rapid on-site diagnostics .

Typical Applications

The EL7342 is widely used in industrial automation applications requiring compact, high-precision DC motor control, such as :

• General Machine Building: For conveyor belts, packaging machines, and handling systems.

• Small Servo Axes: In applications like positioning systems, feed drives, and robotics.

• Laboratory & Testing Equipment: Where precise motor control in a small footprint is needed.
