The Allen-Bradley 22F-D4P2N103 is a PowerFlex 4M series adjustable frequency AC drive from Rockwell Automation, designed for simple, cost-effective motor speed control in industrial applications.
Item No :
22F-D4P2N103Order(MOQ) :
1 PiecePayment :
EXWProduct Origin :
USAShipping Port :
WuhanLead Time :
3-5daysWeight :
3kg| Specification | Description |
|---|---|
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Model | 22F-D4P2N103 |
| Product Family | PowerFlex 4M |
| Product Type | Adjustable Frequency AC Drive (VFD) |
| Input Voltage | 380–480V AC, 3-Phase |
| Output Power | 1.5 kW / 2 HP |
| Output Current | 4.2 A |
| Enclosure Rating | IP20 / NEMA Open Type |
| Frame Size | Frame A |
| Control Method | Volts per Hertz (V/Hz) with slip compensation |
| User Interface | Fixed digital keypad with potentiometer and 4-digit LED display |
| Communication | Integral RS-485 (DSI/Modbus RTU) |
| Brake IGBT | Omitted (No internal brake transistor) |
| EMC Filter | No CE compliant filter |
| Mounting | Panel Mount / DIN Rail (Frame A supports DIN rail) |
| Dimensions (H x W x D) | Approx. 174 x 72 x 136 mm |
| Weight | Approx. 0.9 kg (2.00 lbs) |
| Operating Temperature | Up to 50°C (122°F) with minimal spacing; 40°C (104°F) for zero stacking |
| Lifecycle Status | Active (PM300) |
| Model | Description | Typical Application |
|---|---|---|
| 22F-D4P2N103 (this model) | PowerFlex 4M, 480V, 1.5kW/2HP, 4.2A, Frame A, No Filter | Simple fan/pump control with local keypad |
| 22F-D4P2N113 | Same rating with integrated EMC filter | Installations requiring EMC compliance |
| 22F-D6P0N103 | PowerFlex 4M, 2.2kW/3HP (higher power) | Applications requiring slightly more capacity |
| 22F-D2P5N103 | PowerFlex 4M, 0.75kW/1HP (lower power) | Smaller motor applications |
| 22F-D4P2N104 | PowerFlex 4M, similar rating with different configuration | Alternative feature requirements |
| 25B-D4P0N104 | PowerFlex 525 – Official successor with embedded EtherNet/IP and STO | Modern networked applications requiring safety |
| 25B-D4P0N114 | PowerFlex 525 with integrated EMC filter | Networked applications requiring EMC compliance |
Q1: What is the primary function of the 22F-D4P2N103?
It is a PowerFlex 4M adjustable frequency AC drive used to control the speed of three-phase AC motors. It provides basic V/Hz control for simple applications such as fans, pumps, and conveyors where networking and advanced features are not required.
Q2: What communication options does this drive support?
The drive features integral RS-485 communication supporting the DSI (Drive Serial Interface) protocol, which is compatible with Modbus RTU. This allows for multi-drop network configurations and programming from a PC using a serial converter module .
Q3: Does this drive include a brake transistor?
No. The 22F-D4P2N103 is configured with the brake IGBT omitted . For applications requiring dynamic braking, an external brake chopper or a different drive model with an internal brake transistor is needed.
Q4: Is the PowerFlex 4M still an active product?
Yes, the 22F-D4P2N103 is currently listed as Active (PM300) by Rockwell Automation . However, the PowerFlex 4M series is an entry-level platform, and Rockwell recommends the PowerFlex 523 or 525 for new designs requiring networking, safety, or sensorless vector control.
Q5: Can I use this drive with a ControlLogix or CompactLogix PLC?
Yes, but with limitations. The PowerFlex 4M communicates via RS-485/DSI (Modbus RTU). To connect to a Logix controller, you would need a third-party Modbus RTU scanner or a serial communication module. For native EtherNet/IP integration, the PowerFlex 525 is the recommended choice.
