The ABB HIER460247R1 UN0806B-P V1 is a control card from ABB's legacy HIER series, designed for industrial automation systems. It serves as a signal acquisition and command output node within DCS (Distributed Control Systems), commonly found in manufacturing, energy, and process control applications . Featuring Modbus RTU/RS-485 communication and robust industrial-grade construction, this module provides reliable control in demanding environments..

  • Item No :

    HIER460247R1 UN0806B-P V1

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    Sweden

  • Lead Time :

    3-5days

  • Weight :

    3kg

  • Product Details

    General Information



    Attribute Specification
    Product Type Industrial Control Card
    Order Number HIER460247R1
    Sub-model UN0806B-P V1
    Brand ABB
    Series UN0806B-P Control Module Series
    Product Status Discontinued (MRO supply only)

    Electrical Specifications



    Parameter Specification
    Operating Voltage 24V DC (some variants may support 110-240V AC - verify on nameplate)
    Input Current 10 mA - 1A (configuration dependent)
    Power Consumption ≤ 5W

    Communication & I/O



    Parameter Specification
    Communication Protocol Modbus RTU, RS-485
    Digital Channels 8 inputs / 8 outputs (typical configuration)
    Load Capacity 250V AC / 3A

    Environmental & Physical



    Parameter Specification
    Operating Temperature -20°C to +70°C
    Storage Temperature -40°C to +85°C
    Protection Class IP20 (cabinet installation)
    Dimensions (approx.) 100 × 100 × 50 mm (varies by source)  or 480 × 82 × 180 mm
    Weight Approx. 0.2 - 0.66 kg
    Certifications CE, UL

    Important Note: Specifications vary across supplier documentation. Always verify against the physical module's nameplate before installation .

    Recommended Alternative Models



    Model Number Description Key Differences
    HIER460302R1 UN0824B-P V1 Processor Module Similar HIER series; 24V DC, IP20, Profibus DP communication, 0-55°C operating range
    HIER464920P0001 Current Relay Module Same HIER series family; precision current measurement, relay/analog/digital outputs, IP65 rated, -40°C to +70°C
    HIER466665R0099 NU8976A99 High-Performance Control Module Same HIER series; dual-core CPU, 2x Ethernet, 2x CAN bus, Modbus/CANopen protocols, 256MB RAM, IP65

    Compatibility Note: Due to version-locking ("P" and "V1" suffixes may indicate specific firmware or slot assignments), direct substitution requires verification of the complete host system BOM and rack model .

    FAQs

    1: What is the primary function of the HIER460247R1 UN0806B-P V1?

    A: It is a control card responsible for signal acquisition from field devices and command output execution within ABB industrial automation systems. It typically serves as a logic, regulation, or communication interface card in older ABB HIER/HIEE series racks .

    2: Why is the "UN0806B-P V1" suffix important?

    A: The "P" and "V1" designations represent version/firmware locks. Modules with different suffixes may not be compatible with the same rack slot or system configuration. Always match the exact suffix when sourcing replacements .

    3: What operating voltage does this module require?

    A: Most sources indicate 24V DC, though some documentation references 110-240V AC variants. This is critical to verify on the physical module's nameplate before applying power, as incorrect voltage will cause immediate damage.
