The ABB TK503 (1TNE968901R1100) is an original programming cable designed to connect a PC to ABB AC500 programmable logic controllers (PLCs) and related industrial automation equipment. This cable provides a convenient and reliable bridge between a computer's USB port and the RS485 D-Sub 9-pin serial interface commonly found on ABB AC500 CPUs and communication modules.
With a length of 3 meters, the TK503 offers sufficient reach for flexible workstation setup and machine-side programming in industrial environments. It is a genuine, high-quality ABB accessory intended for commissioning, programming, firmware updates, and troubleshooting applications.
Item No :
TK503 1TNE968901R1100Order(MOQ) :
1Payment :
EXWProduct Origin :
SwedenShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
3kgProducts Description
ABB TK503 1TNE968901R1100 Programming Cable
D-Sub to USB Programming Cable for ABB AC500 PLC Series
| Model Number | TK503R0 1TNE968901R1100 |
| Place of Origin | Sweden |
| Dimension/Weight | 3kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
Genuine ABB Programming Cable: Designed specifically for the ABB AC500 and AC500-eCo PLC series, ensuring compatibility and reliable communication.
USB to RS485 D-Sub Connection: Bridges modern PCs (USB) with industrial controllers (RS485 9-pin D-Sub), eliminating the need for a separate serial port or converter.
Standard 3-Meter Length: Provides ample working distance between a PC and a PLC cabinet, allowing flexible positioning of the engineer's workstation.
Industrial-Grade Reliability: Designed and tested for robust, stable data transfer in industrial environments, with effective noise immunity to ensure error-free communication.
Wide Temperature Range: Capable of operating in temperatures from 0°C to +60°C and can be stored in conditions as cold as -40°C, making it suitable for harsh industrial use.
User-Friendly Design: The cable is a plug-and-play solution with a D-Sub connector on one end and a USB connector on the other. Driver support is typically included or can be easily obtained from ABB's official resources.
| Category | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | TK503 |
| Ordering Number | 1TNE968901R1100 |
| Product Type | Programming / Communication Cable |
| Compatibility | ABB AC500, AC500-eCo PLC Series, and compatible serial devices |
| Connection Type (PC) | USB |
| Connection Type (Device) | D-Sub 9-pin (RS485) |
| Cable Length | 3 meters (approx. 9.8 feet) |
| Degree of Protection | IP20 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Weight | Approx. 3 kg |
| Country of Origin | Sweden |
| Detail | Information |
|---|---|
| Condition | New & Original |
| Stock Status | In Stock |
| Warranty | 12 Months |
| Shipping Port | Wuhan, China |
| Lead Time | 3-5 Working Days |
| Payment Terms | T/T, Western Union |
Packing&Delivery
In order to save the freight and reduce your budget, we choose the packaging for environment-friendly. We use foam board with 3 cm thick to fill in all around the box inside to protect parts, then use carton to pack the parts, but if they are too heavy, we will customized the wooden box for them.Shipping term DHL Fedex TNT EMS UPS.
