The ABB PFEA112-65 is a high-precision tension electronics unit designed for demanding industrial web processing applications. This field-mountable unit processes signals from up to two ABB Pressductor® magneto-elastic load cells (PFTL or PFCL series) and provides real-time tension measurement and control for materials such as paper, film, foil, textiles, and cable .
The -65 designation indicates the IP65 enclosure version — a rugged, wall-mounted housing that provides protection against dust and water jets . Unlike the IP20 DIN-rail variant (PFEA112-20), this version is specifically engineered for direct installation in harsh, dirty, or wet environments such as paper mills, metal processing lines, and outdoor installations .
This module is available with two ordering numbers — 3BSE030369R0065 and 3BSE050091R65 — which represent the same functional unit under different ABB ordering systems.
Item No :
PFEA112-65Order(MOQ) :
1Payment :
EXWProduct Origin :
SwedenShipping Port :
Wuhan, Hubei, ChinaLead Time :
3-5 daysWeight :
0.5kgProducts Description
ABB PFEA112-65 3BSE030369R0065 / 3BSE050091R65 Tension Electronics Unit
IP65 High-Protection Tension Controller for Web Processing Applications
| Model Number | PFEA112-65 3BSE030369R0065 3BSE050091R65 |
| Place of Origin | Sweden |
| Dimension/Weight | 9.6*11.9*5.4cm / 0.2kg |
| Condition | New and Original |
| Warranty | 1 year |
| Shipping term | DHL Fedex TNT EMS UPS |
| Payment | TT / Western Union |
| Delivery time | 3-5 days |
| Service | 24 Hours Online Service |
IP65 Rugged Enclosure: Dust-tight and protected against low-pressure water jets, enabling direct machine-side installation without additional cabinet housing
Dual Load Cell Input: Supports two ABB Pressductor® magneto-elastic tension sensors (PFTL/PFCL series) for measuring total, individual, or differential web tension
High Measurement Accuracy: ±0.1% to ±0.5% full-scale precision, ensuring reliable tension control in critical processes
Flexible Output Options: Provides configurable analog outputs (0-10V / 0-20mA / 4-20mA) and digital I/O for integration with PLCs, drives, and DCS systems
Profibus-DP Communication: Enables seamless data exchange with ABB System 800xA and other industrial networks
Local Operator Interface: Built-in 2×16 character multilingual LCD display and keypad for on-site configuration, calibration, zero adjustment, and status monitoring — no PC required
Advanced Signal Processing: Digital filtering options (15–1500 ms) to suppress vibration noise and improve measurement stability in high-interference environments
Comprehensive Diagnostics: Sensor break detection, hardware fault monitoring, and self-diagnostic functions for proactive maintenance and reduced downtime
Versatile Power Supply: Supports 24 VDC (18–36 VDC) with optional 100–240 VAC variant, providing flexibility for different installation requirements
| Category | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | PFEA112-65 |
| Ordering Numbers | 3BSE030369R0065 / 3BSE050091R65 |
| Product Type | Tension Electronics Unit / Tension Controller |
| Application | Web tension measurement and closed-loop control |
| Parameter | Detail |
|---|---|
| Load Cell Inputs | 2 channels (ABB PFTL/PFCL Pressductor® sensors) |
| Excitation Signal | 330 Hz, 0.5 A RMS AC |
| Max Load | 2 load cells + 5 Ω cable resistance |
| Measurement Accuracy | ±0.1% to ±0.5% FS |
| Parameter | Detail |
|---|---|
| Analog Outputs | 1× voltage (0-10V) / 1× current (0/4-20mA), configurable |
| Digital I/O | 2× digital inputs, 2× digital outputs |
| Filter Options | 15 / 30 / 75 / 250 / 750 / 1500 ms |
| Parameter | Detail |
|---|---|
| Supply Voltage (DC) | 24 VDC (18–36 VDC) |
| Supply Voltage (AC) | 100–240 VAC (optional variant) |
| Power Consumption | 7.5 W (DC) / 12 W (AC) |
| Protection Rating | IP65 (dust-tight, water-jet protected) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Dimensions | Approx. 170×105×32 mm |
| Weight | Approx. 1.0–2.0 kg (depending on enclosure) |
| Mounting | Wall mount / machine-side mount |
| Certifications | CE, cULus, UL508, EMC Directive |
The PFEA112-65 processes weak magneto-elastic signals from the Pressductor® sensors and performs precision signal conditioning to calculate :
Sum Tension — Total tension measured across both load cells
Difference (Differential) Tension — Difference between the two sides
Individual Sensor Signals — Per-sensor measurement values
| Mode | Description |
|---|---|
| Manual Control | Direct operator-set output for simple applications |
| Automatic PID Control | Closed-loop regulation of tension to maintain setpoint |
| Constant Tension | Maintains steady tension regardless of speed variation |
| Taper Tension | Reduces tension with increasing roll diameter (winding applications) |
Profibus-DP Fieldbus: Transmits tension values, status, and diagnostic information to upper-level PLC/DCS systems
Analog Outputs: Directly drives drives, brakes, or PLC analog input channels for closed-loop control
Local Display: 2×16 character LCD provides real-time tension readings in user-selectable units (N, kN, kg, lbs)
| Feature | PFEA112-20 (IP20) | PFEA112-65 (IP65) |
|---|---|---|
| Enclosure | Open module, DIN-rail mount | Sealed housing, wall mount |
| Protection | IP20 (cabinet installation only) | IP65 (field installation) |
| Mounting | DIN rail (inside cabinet) | Machine-side direct mount |
| Power Supply | 24 VDC only | 24 VDC or 100–240 VAC |
| Best Application | Clean control rooms, panels | Paper mills, metal processing, wet/dirty environments |
Key Advantage: The IP65 version enables installation directly on production machinery, significantly reducing the distance of analog signal cables and minimizing interference risks .
The PFEA112-65 is widely deployed across industries requiring precise tension control in harsh environments :
| Industry | Application |
|---|---|
| Paper & Pulp | Wet end felt tension, press section monitoring, paper machine lines |
| Metal Processing | Steel rolling, aluminum foil processing, pickling lines |
| Film & Plastics | Lithium battery separator coating, optical film, stretch film production |
| Textile & Printing | Fabric tension control, printing presses, coating lines |
| Cable Manufacturing | Wire drawing machines, cable insulation layer thickness control |
| Automotive | Lamination processes, composite materials |
