Product Overview: SIEMENS 6ES7153-2BA10-0XB0 Controller Module
SIEMENS 6ES7153-2BA10-0XB0 is a PROFIBUS DP interface module (IM 153-2 HF) for the ET 200M distributed I/O system, connecting up to 12 S7-300 signal modules to a PROFIBUS master. It supports redundancy, isochronous mode, and provides 1 ms time-stamping for high-availability and precision control applications.
Brand Name: SIEMENS
Model Number: 6ES7153-2BA10-0XB0
Condition: 100% New and Original
Lead Time: 3-5 Days
Warranty: 1 YearProduct Specification
Key Specifications
| Item |
Specifications / Features |
| Product Type |
ET 200M Interface Module IM 153-2 HF |
| Supported I/O Modules |
Up to 12 S7-300 series signal modules |
| Maximum Address Range |
244 bytes each for inputs and outputs |
| System Platform |
Compatible with SIMATIC S7-400H high-availability systems, soft redundancy, and S5 redundant systems |
| Supply Voltage |
Rated 24 V DC (20.4 V ~ 28.8 V); typical power consumption 5.5 W |
| Backplane Bus Power |
Provides up to DC 5 V / 1.5 A to I/O modules on the backplane |
| Redundancy Support |
Natively supports interface module redundancy with "Flying Redundancy" on PROFIBUS networks |
| Clock Synchronization & Time Stamping |
Supports clock synchronization; provides time stamps with 1 ms accuracy for digital signal changes, ideal for Sequence of Events (SOE) recording |
Key Features & Advantages
-
Powerful Expansion & Performance – Compared to earlier versions, this module increases the number of connectable I/O modules from 8 to 12, significantly enhancing the expansion capability of a single ET 200M station. It also supports isochronous mode, optimizing data read/write timing for high-precision motion control applications with demanding cycle time requirements.
-
High Availability with Redundancy – One of the module's standout features is its redundancy capability. It can be used in pairs to achieve redundant communication on PROFIBUS networks. When one interface module or communication path fails, the system automatically switches over, ensuring continuity in mission-critical process control.
-
Precise Time Stamping – The module features built-in time stamping functionality, allowing digital input signal changes to be tagged with 1 ms accuracy. This is essential for applications requiring precise Sequence of Events (SOE) recording for fault diagnosis and post-incident analysis.
Main Applications
The 6ES7153-2BA10-0XB0 is widely used in applications with high demands for system availability, expandability, and time synchronization, such as:
-
Process Industries – As the communication interface for remote I/O stations in redundant systems for oil & gas, chemical, and pharmaceutical plants.
-
Manufacturing – For distributed field signal acquisition and high-precision motion control in automotive and machinery production lines.
-
Power Generation – In substation automation and other applications requiring precise event sequence recording.
Functions
Ease Of Maintenance: Choose modules that are easy to maintain and replace.
Versatility Of Spare Parts: Ensures that the selected modules are readily available on the market.
Scalability: Consider the expansion functions that may be required in the future, and choose a PLC module that is easy to expand.
Special Function Requirements: Select modules with special functions according to specific application scenarios.
