Beckhoff EL3048 EtherCAT Terminal Analog Input Module, 8 Channels, 4-20mA, 16-bit Resolution, Beckhoff PLC Spare Parts
Beckhoff EL3048 EtherCAT terminal LED status indicators Power channel Bus communication
The Beckhoff EL3048 module is mounted on an EtherCAT terminal block and mates with an EK1100 coupler.

Beckhoff EL3048 EtherCAT Terminal

The EL3048 analog input terminal processes signals in the range between 0 and 20 mA. The current is digitized to a resolution of 12 bits and is transmitted (electrically isolated) to the higher-level automation device. The EL3048 EtherCAT Terminal combines eight channels in one housing. The power contacts are connected through. The 0 V power contact is used as reference ground connection for the inputs. The signal state of the EtherCAT Terminal is indicated by light emitting diodes.

  • Item No :

    EL3048

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    Germany

  • Shipping Port :

    Wuhan, Hubei, China

  • Lead Time :

    3-5 days

  • Weight :

    0.5kg

  • Prodoct Overview: Beckhoff EL3048 EtherCAT Terminal

    Beckhoff EL3048 is an 8-channel analog input EtherCAT Terminal for the Beckhoff I/O system. Its core function is to process analog signals in the range from 0 to 20 mA, digitize them with a resolution of 12 bits, and transmit the data in an electrically isolated form to the higher-level automation device.



    Brand Name: Beckhoff

    Model Number: EL3048

    Condition: 100% New and Original

    Lead Time: 3-5 Days



    Warranty: 1 Year



    Key Specification

    Item Specifications / Features
    Number of Channels 8 (single-ended inputs)
    Signal Type 0…20 mA
    Resolution 12 bits (16-bit presentation incl. sign)
    System Platform Beckhoff EtherCAT I/O System
    Conversion Time 1.25 ms default setting (configurable, multiplex)
    Measurement Error < ±0.3% (relative to full scale value)
    Electrical Isolation 500 V (E-bus/signal voltage)
    Special Features Standard and compact process image; activatable FIR/IIR filters; limit value monitoring
    Diagnostics Signal status and overload indicated via LEDs

    Core Features & Advantages

    • High Channel Density & Space-Saving Design: The module's standout feature is its combination of eight analog input channels in a single, compact 12 mm housing. This high-density design allows for significant space savings in the control cabinet, making it ideal for applications with a large number of analog signals.

    • High Precision & Measurement Accuracy: With a 12-bit resolution and a high-precision internal resistance of typ. 85 Ω, the EL3048 ensures accurate current measurement. The measurement error of less than ±0.3% relative to the full scale value guarantees reliable signal acquisition for precise process control.

    • Flexible & User-Friendly Configuration: Configuration is straightforward, as the terminal requires no address or configuration settings and is automatically recognized by the EtherCAT system. It also offers standard and compact process image modes, activatable FIR/IIR filters for signal smoothing, and limit value monitoring features to enhance diagnostic capabilities and reduce the CPU load.

    • Robust Design for Harsh Environments: The EL3048 is designed for industrial reliability, featuring a wide operating temperature range from -25°C to +60°C and a storage temperature range of -40°C to +85°C. It is compliant with EN 60068-2-6/EN 60068-2-27 for vibration/shock resistance and EN 61000-6-2/EN 61000-6-4 for EMC immunity/emission. The terminal is also ATEX and IECEx approved for use in potentially explosive atmospheres (II 3 G Ex ec IIC T4 Gc).

    Typical Applications

    The EL3048 is widely used in industrial and building automation applications requiring the acquisition of 0…20 mA analog signals, such as:



    • Process Automation: Connecting pressure, temperature, and flow sensors for monitoring and control in chemical, pharmaceutical, and food processing plants.

    • Machine Building: Integrating with various transmitters and sensors for manufacturing and packaging machinery.

    • Test & Measurement: Data acquisition from multiple sensors in testing and quality assurance processes

    Recommended Products – System Components

    The following products are commonly used alongside the EL3048 in a Beckhoff EtherCAT I/O system, as identified from Beckhoff product information and industry sources :



    Product Model Description
    EtherCAT Coupler (100BASE-TX) EK1100 Connects EtherCAT Terminals (ELxxxx) to a 100BASE-TX EtherCAT network; 2 x RJ45 bus interfaces; data transfer rate: 100 Mbaud
    EtherCAT Bus Coupler (E-bus) EK1101 EtherCAT Bus Coupler for direct connection of EtherCAT Terminals
    Ethernet/EtherCAT Cable (Fixed Installation) ZB9010 Industrial Ethernet/EtherCAT cable, CAT5e, 4-wire
    Ethernet/EtherCAT Cable (Drag-chain Suitable) ZB9020 Industrial Ethernet/EtherCAT cable, CAT5e, 4-wire, suitable for continuous flexing applications
    EtherCAT Bridge Cable ZK1090-9191-xxxx EtherCAT bridge cable for connecting Beckhoff components; available in various lengths (0.17 m, 0.5 m, 1.0 m, 2.0 m, 3.0 m, 5.0 m)
    RJ45 Connector (Field Assembly) ZS1090-0003 RJ45 connector, 4-pin, IP20, for field assembly
    RJ45 Connector (Field Assembly) ZS1090-0005 RJ45 connector, 8-pin, IP20, for field assembly

    Comparison with Similar Models

    The EL30xx series includes several analog input terminals with different channel counts and resolutions . The following table compares the EL3048 with other common models in this family:



    Model Channels Signal Resolution Conversion Time Application Recommendation
    EL3048 8 0…20 mA 12 bit 1.25 ms High-density, cost-effective 8-channel current input for applications with many 0–20 mA sensors
    EL3044 4 0…20 mA 12 bit ~500 µs Faster conversion speed for applications requiring quicker response times; lower channel count
    EL3144 4 0…20 mA 16 bit ~500 µs Higher resolution (16-bit) for applications requiring greater measurement precision
    EL3042 2 0…20 mA 12 bit 0.625 ms Low-density option for applications with very few sensors; smallest channel count



    Selection Guidance



    Scenario Recommended Product
    High-density, cost-sensitive 0–20 mA measurement EL3048 – 8 channels in 12 mm width; best value per channel
    Faster conversion speed required EL3044 – ~500 µs conversion time vs. 1.25 ms
    Higher measurement resolution needed EL3144 – 16-bit resolution for greater precision
    Limited channel count required EL3042 – 2-channel option for simple applications
    Pluggable wiring preferred ES3048 – Same functionality with pluggable wiring level for easy replacement
