Allen-Bradley 20BC260A3ANNAND0 PowerFlex 700 AC Drive (260A, 132kW, 400V, ControlNet, Vector Control, No Braking IGBT, Rockwell Spare Part)
20BC260A3ANNAND0 High-power motor speed control (pumps, fans, compressors), industrial automation, ControlNet network.

Allen-Bradley 20BC260A3ANNAND0 PowerFlex 700 AC Drive

The Allen-Bradley 20BC260A3ANNAND0 is a high-power PowerFlex 700 series adjustable frequency AC drive from Rockwell Automation, engineered for demanding industrial motor control applications. This 400V class drive delivers a rated output current of 260 A, making it suitable for large-scale machinery, process lines, and heavy industrial equipment requiring precise motor speed and torque regulation.

The PowerFlex 700 platform is recognized for its compact design, flexible packaging options, and reliable operation across applications including material handling, pumps, fans, and process control systems.

  • Item No :

    20BC260A3ANNAND0

  • Order(MOQ) :

    1

  • Payment :

    EXW

  • Product Origin :

    USA

  • Shipping Port :

    Wuhan, Hubei, China

  • Lead Time :

    3-5 days

  • Weight :

    10kg

  • Key Features



    Feature Description
    High Power Output 260 A rated output current for demanding motor loads
    Vector Control Supports V/Hz and Sensorless Vector Control for precise motor regulation
    Integrated Braking IGBT Built-in brake IGBT for controlled deceleration in high-inertia applications
    EMC Filtering Internal EMC filter meets CE directives without additional panel space
    Standard I/O 6 digital inputs, 2 analog inputs, 2 relay outputs, and 1 analog output
    Rugged Construction IP20 / NEMA Type 1 panel-mount enclosure for protected control cabinet installation

    Technical Specifications

    General



    Parameter Specification
    Manufacturer Allen-Bradley / Rockwell Automation
    Series PowerFlex 700
    Part Number 20BC260A3ANNAND0
    Product Type Adjustable Frequency AC Drive

    Power Ratings



    Parameter Specification
    Input Voltage 380–480V AC, 3-phase, 50/60 Hz
    Rated Output Current 260 A
    Normal Duty Power 132 kW (175 HP) @ 400V AC
    Output Voltage Range 0–Input Voltage, 3-phase PWM
    Output Frequency Range 0–500 Hz (Enhanced Control)

    Configuration Details



    Parameter Specification
    Enclosure Panel Mount – IP20, NEMA/UL Type 1
    Interface Module Full Numeric LCD with Brake
    Control Type Vector Control
    Communication ControlNet (Coax) – DPI Module
    EMC Filtering Second Environment Filter per CE EMC directive
    Brake IGBT Installed
    Internal Brake Resistor No (external required)

    Environmental



    Parameter Specification
    Operating Temperature 0 to 50°C without derating
    Storage Temperature -40 to 70°C
    Enclosure Rating IP20 / NEMA Type 1

    Part Number Decoding



    Position Code Meaning
    20B Product Family PowerFlex 700
    C Voltage Class 400V AC
    260 Output Current 260 Amps
    A Frame Size Frame 6
    3 Enclosure Panel Mount, IP20, NEMA Type 1
    A Interface Module Full Numeric LCD with Brake
    N Control Type Standard Control
    N Communication ControlNet (Coax)
    A Filtering CE EMC Filter
    N Brake IGBT Installed
    D Feedback Encoder Feedback
    0 Brake Resistor No Brake Resistor

    Applications

    The PowerFlex 700 20BC260A3ANNAND0 is suitable for high-power industrial motor control applications:

    • Material Handling: Large conveyor systems, sortation equipment, and bulk material transport

    • Process Industries: Pumps, fans, and compressors in chemical, petrochemical, and water treatment facilities

    • Manufacturing: Heavy machinery, production lines, and machine tool auxiliaries

    • Infrastructure: HVAC systems, energy management, and large-scale ventilation

    Key Benefits



    Benefit Description
    High Power Density 260 A output handles demanding motor loads up to 132 kW / 175 HP
    Flexible Control Modes Multiple control algorithms (V/Hz, SVC) suit diverse application requirements
    Integrated Braking Control Built-in brake IGBT eliminates external braking hardware for simpler installations
    Network Integration ControlNet communication enables seamless integration with Rockwell Automation control systems
    Proven Reliability Established PowerFlex platform with extensive global install base

    Important Notes

    • Lifecycle Status: This product is discontinued (end-of-life). It is available through aftermarket suppliers while stock lasts .

    • Replacement Path: Rockwell Automation encourages migration to current-generation drives (e.g., PowerFlex 750-Series) for new installations.

    • Brake Resistor: The drive includes a brake IGBT but does not include a built-in brake resistor. External braking hardware is required for dynamic braking applications.

    • Enclosure: IP20 rating requires installation in a protected control cabinet or enclosure.

    • Encoder Feedback: This configuration (indicated by "D" in the feedback position) includes encoder feedback capability.

    • Reference Documentation: Installation and programming information is available in PowerFlex 700 User Manual (Publication 20B-UM002) and related Rockwell Automation publications.

    FAQ

    Q1: What is the power rating of the 20BC260A3ANNAND0?

    A: The drive is rated at 132 kW (175 HP) in Normal Duty applications, with a rated output current of 260 A at 400V AC, 3-phase .

    Q2: Is the PowerFlex 700 series still in production?

    A: No. Rockwell Automation has discontinued the PowerFlex 700 series. The product is no longer available for sale from the manufacturer, but aftermarket suppliers may have stock .

    Q3: What communication network does this drive support?

    A: This specific configuration includes ControlNet (Coax) network support via a DPI communication module.

    Q4: Does the drive include a braking resistor?

    A: No. While the drive includes a brake IGBT for controlling external braking resistors, the resistor itself is not included with this model.

    Q5: What enclosure rating does this drive have?

    A: The drive is rated IP20 / NEMA Type 1, designed for panel mounting inside a protected electrical enclosure.

    Q6: What control modes are available?

    A: The drive supports Volts per Hertz (V/Hz) and Sensorless Vector Control (SVC) for motor regulation .

    Q7: What is the maximum output frequency?

    A: The maximum output frequency is 500 Hz with Enhanced Control .

    Q8: Does this drive include an HMI display?

    A: Yes, this configuration includes a Full Numeric LCD interface module with brake control.

    Q9: Does this drive support encoder feedback?

    A: Yes. This configuration (indicated by "D" in the feedback position) includes encoder feedback capability.

    Q10: What documentation is available for this drive?

    A: Key reference publications include the PowerFlex 70/700 Reference Manual (PFLEX-RM001) and PowerFlex 700 User Manual (20B-UM002) .
